Specifications, 7 dimensions – JVC DT-V100CG User Manual

Page 23

background image

23

DT-V100CG

Multi-Format Monitor

10" measured diagonally

Width

:176.9 mm (6

15

/

16

")

Height

:137.6 mm (5

3

/

8

")

Diagonal

:224.5 mm (8

13

/

16

")

H : 15 kHz
V : 50 Hz/60 Hz

6 MHz (–3 dB)

Video:

280 TV lines

1080/60i:

230 TV lines

Composite signal input/output terminals

VIDEO A/VIDEO B: 2 lines, BNC connector X 4 (1 Vp-p, 75

Ω)

* The input (IN) and output (OUT) terminals are bridge-connected. (Auto termination)

External synchronized input/output terminals

EXT. SYNC: 1 line, BNC connector X 2 (0.3 Vp-p – 4 Vp-p, 75

Ω)

* The input (IN) and output (OUT) terminals are bridge-connected. (Auto termination)

Remote input/output terminals

RS-485: Serial connection, 1 line, RJ-45 connector (8-pin) X 2, compliant to RS-485
MAKE/TRIGGER: Point-of-contact connection, 1 line, RJ-45 connector (8-pin) X 1

INPUT A/B: NTSC (3.58 MHz), PAL (4.43 MHz), B/W (50 Hz/60 Hz)
INPUT C/D: Depends on the input unit (option) attached to the monitor. Refer to the input unit’s

manual for details.

Operating temperature:

5°C – 35°C (41°F – 95° F)

Operating humidity:

20% – 80% (non-condensing)

120 V/220-240 V AC, 50 Hz/60 Hz

0.9 A (120 V AC)/0.6 A (220-240 V AC)

Width:

222 mm (8

3

/

4

")

Height:

220 mm (8

3

/

4

")

Depth:

319.3 mm (12

5

/

8

")

(Dimensions are the same when the wide mask is attached. The input unit is not included.)

7.1 kg (15.7 lbs) (not including the wide mask and the input unit)

AC power cord
Power cord holder x 1 (case and cover)
Screws x 2 (Power cord holder)
Wide Mask x 1
Screws x 4 (Wide Mask)

Specifications

Model

Type

Picture Tube

Effective Screen Size

Scanning Frequency

Video Band

Horizontal Resolution

Input/Output Terminals

Compliant Video Signal

Environmental
Conditions

Power Requirements

Power Consumption

Dimensions

Weight

Accessory

* Illustrations and pictures used in this manual have been exaggerated, abbreviated or compounded for explanatory purposes only.

The appearance of the actual product may differ slightly.

* Dimensions and weight are approximate.
* E. & O.E. Design and specifications subject to change without notice.

7 Dimensions

Unit : mm (inch)

Front View

Side View

Asterisks(*) are used to indicate front panel dimensions.

178

(7

1

/

8

")*

99.5

(4")*

183

(7

1

/

4

")*

140

(5

5

/

8

")*

222

(8

3

/

4

")

164

(6

1

/

2

")

220

(8

3

/

4

")

222 (8

3

/

4

")

63.5 (2

1

/

2

")

307.8 (12

1

/

8

")

1.5

(

1

/

16

")

319.3 (12

5

/

8

")

7

(

3

/

8

")

7

(

3

/

8

")

Front View
(with the wide mask attached)
