Jackson 700 Series - Manual (Page 12)

Rotisserie Kit Completed Installation
Rotisserie Rod Bushing Placed on the
cut out provided on the Inner Hood
Upper Flavor Shield, Cooking Grid Installation.
at all protective plastic has
Remove the Upper Flavor Shields form the Packaging. Please ensure th
been
moved from these parts.
hese Upper Flavor shields should be placed on the pins provided on the Firebox Front and Rear. Ensure
at all of the Upper Flavor Shields have been installed correctly on the pins provided or the unit will not work
orrectly. See diagram below.
nce the Upper Flavor Shield have been installed the Cooking Grids can be installed into the Grill. Place the
ooking grills on the upper ledge of the firebox as shown below.
re
T
th
c
O
c
Upper Flavor Shield installation.
Place the Upper Flavor Shields on the pins
provided on the Firebox Front and Rear
Cooking Grid Installation.
Place the Cooking Grids X 2 on the upper
ledge as shown.
12
