Rotisserie kit installation (if equipped) – Jackson 700 Series User Manual
Page 11

After the Side Shelves
ossible.
Secure the Condiment
Bins to the Display Panel
using the screws from the
securing plates.
have been installed, ensure the Grill Head is pushed back in the pedestal as far as
through the side of the Condiment bins and
p
With the screws removed from the securing straps, place a screw
secure the Condiment Bins to the Display Panel.
ROTISSERIE KIT INSTALLATION (If Equipped)
1
Install the Motor Mounting Bracket supplied to the Right hand side of the Inner Hood. (If not
already installed)
3
Place the Rotisserie Rod into the Motor. Slide the Rotisserie Rod Bushing over the opposite end
of the Rod and drop into the cut out provided in the inner Hood Side. Tighten the thumb-screw
provided with the Rotisserie
4
Place the forks and Counter
d location.
5
When in use, spin the rod with your de
ht of the food is at
the bottom. Install the Counter Balance Straight up to e
Rotisserie system.
1
Rotisserie Rod Handle
2
Install the Motor on the Motor Bracket.
Rod Bushing.
Balance on the Rotisserie Rod in the desire
sired food until the weig
ffectively balance the
2
Rotisserie Rod Bushing
3
Counter Balance
4
Rotisserie Forks X 2
5
Rotisserie Rod
6
Rotisserie Motor Mount
7
Rotisserie Motor
11
