17

ENGLISH

Specifications

7 General

Model name

DT-V9L1D

Type

Multi format LCD monitor

Screen size

Type 9 wide format

Aspect ratio

15:9

LCD panel

9˝ wide, IPS-Pro

Effective screen size

Width: 195 mm
Height: 117 mm

Number of pixels displayed

800 x 480

Number of colors displayed

16.20 million

Viewing angle (TYP.)

170° (Horizontally), 170° (Vertically)

Panel brightness (at least)
(TYP.)

350 cd/m

2

Contrast ratio (TYP.)

400:1

Compliant video signal format

☞ “Available signals” on page 9

Format

HD SDI: BTA S-004B, SMPTE292M
SD SDI: ITU-R BT.656: 525/625

SMPTE259M: 525

EMBEDDED AUDIO: SMPTE299M, SMPTE272M

Audio output

Internal speaker: 1.0 W

Operating conditions

Operating temperature: 0°C – 40°C
Operating humidity: 20 % – 80 % (non-condensing)
* Slightly variable depending on ambient conditions for installation.

Power requirements

AC 120 V/AC 220 – 240 V, 50 Hz/60 Hz
DC 12 – 17 V

Rated current

0.35 A (AC 120 V)/0.25 A (AC 220 – 240 V)
1.7 A (DC 12 – 17 V)

External dimensions
(excluding protruding parts)

Width: 222.4

mm

Height:

218 mm (at the higher position), 181 mm (at the lower position),

176 mm (without stand)

Depth:

185 mm (at the higher position), 202 mm (at the lower position),

116 mm (without stand)

Weight

3.6 kg (with the stand)
2.7 kg (without the stand)

Accessories

AC power cord x 2, Power cord holder x 1, Screw x 2 (for power cord holder),
Protective filter x 1, Screw (for protective filter) x 4

• For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed,

and may be slightly different from actual products.

• Design and specifications are subject to change without notice.
• All company names and product names mentioned herein are used for identification purposes only, and may

be the trademarks or registered trademarks of their respective companies.

7 Input/output terminals

Video

VIDEO/COMPONENT
(IN/OUT)

VBS/Y
Composite signal/analog component (Y) signal input/output:

1 line, BNC connector x 2

1 V(p-p), 75

* The input (IN) and output (OUT)

terminals are bridge-connected (auto
termination)

P

B

, P

R

Analog component (P

B

, P

R

) signal input:

1 line, BNC connector x 2

0.7 V(p-p), 75

E. AUDIO HD/SD SDI (IN)

Digital signal input (compatible with EMBEDDED AUDIO signals):

auto detection, 1 line, BNC connector x 1

E. AUDIO HD/SD SDI (OUT)

Digital signal output (compatible with EMBEDDED AUDIO signals):

1 line, BNC connector x 1

Au

d

io

AUDIO (IN/OUT)

Analog audio signal input/output:

1 line, RCA connector x 2,

500 mV (rms), high impedance

* The input (IN) and output (OUT)

terminals are bridge-connected (auto
termination)

Exter

nal

control

REMOTE (MAKE/TRIGGER)

☞ “Using the MAKE/TRIGGER system” on page 14

REMOTE (RS-232C)

☞ “Using the RS-232C system” on page 15

Use the Anton Bauer Dionic 90 (mount: QR DXC-M3A) external battery.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

Notice on transportation
This monitor is precision equipment and needs dedicated packing material for transportation.
Never use any packing material supplied from sources other than JVC or JVC-authorized dealers.
