6.1.2. Internal sync out/WEN out
On pin #7 on 9 pin sub-D connector, the factory setting is the internal composite sync signal out.
By jumper settings it can be changed to WEN out.
Refer to “7. Configuring the Camera.”
To use this mode:
Set function on PK8407: JP303 o, JP304 s for sync output. Factory default.
JP303 s, JP304 o for WEN output.
6.1.3. Internal pixel clock out
The internal pixel clock can be output on pin #9 on the 12 pin connector. As factory setting it is
not connected.
Refer to “7. Configuring the Camera.”
To use this mode:
Set function on PK8407: JP310 o, for no pixel clock out. Factory default.
JP310 s, for pixel clock out.
Important notes on using this mode.
• If not used, the pixel clock should not be output.
6.1.4. VBS out on pin#4 12 pin.
On pin #4 on the 12 pin connector, the video signal can be output as a composite signal.
Refer to “7. Configuring the Camera.”
To use this mode:
Set function on PK8404: SW604-1 on for VBS video signal out on pin #4 12 pin. Factory default.
SW604-1 off for no signal out on pin #4 12 pin.
6.1.5. Y out/VBS out on pin#6 9 pin sub-D.
The signal output on pin #6 on the 9 pin sub.D connector can be changed from Y output to
composite video output.
Refer to “7. Configuring the Camera.”
To use this mode:
Set function on PK8404: SW604-2 off, SW604-3 on for Y out on pin #6 9 pin. Factory default.
SW604-2 on, SW604-3 off for VBS out on pin #6 9 pin.
6.1.6. Green out/sync on green on pin#4 9 pin sub-D.
The green signal output on pin #4 9 pin sub-D can be changed to be composite sync on green.
Refer to “7. Configuring the Camera.”
To use this mode:
Set function on PK8404: SW604-4 off for green video out on pin #4 9 pin. Factory default.
SW604-4 on for sync on green out on pin #4 9 pin.
