CV-M91
- 21 -
7.3. RS-232C control
The CV-M91 camera functions can be set up via the RS-232C port on the 6 pin HR connector. The
JAI camera control tool for CV-M91 can be used for it.
To use this mode:
Set function: Control. SW1-8 on rear to ON. RS-232C. (Switch setting before power on).
Other functions
Important notes on using this mode.
•
Communication setting.
Baud Rate 9600 bps
Data Length 8 bit
Start Bit 1 bit
Stop Bit 1 bit
Parity None
Xon/Xoff Control None
RS 232C cable
TXD
RXD
GND
1 CD
4 DTR
6 DSR
2 RXD
3 TXD
5 GND
7 RTS
8 CTS
9 CI
9 pin
D-con
PC COM
PORT
CAMERA
TXD
RXD
GND
1 CD
4 DTR
6 DSR
2 RXD
3 TXD
5 GND
7 RTS
8 CTS
9 CI
9 pin
D-con
PC COM
PORT
CAMERA
7.4. CV-M91command list
The following functions can be controlled via the camera control tool.
Shutter speed
1/60 to 1/10,000 sec.
Mode
Normal, random trigger
Scanning
2.1 interlaced, non-interlaced
Accumulation
Frame,
field
Gamma
Gamma 1.0, gamma 0,45
AGC
AGC off, AGC on, manual gain, AGC reference level
CCD iris
CCD iris on. CCD iris off, CCD iris reference level
White balance
One push, manual, red gain, blue gain, green gain
White clip level
Red white clip, blue white clip, green white clip
Offset level
Red offset, blue offset, green offset
Load user settings
Load factory, user 1, user 2
Save user settings
Save user 1, save user 2. (Last saved user settings become default at next power-up.)
