CV-M91

- 24 -

9.2. Specification table

Specifications

CV-M91P

CV-M91N

Scanning system

CCIR PAL, 25 frames/sec.

625 lines, 2:1 Interlaced

EIA NTSC. 30 frames/sec.

525 lines, 2:1 Interlaced

Frame rate

50 Hz

59.94 Hz

Line frequency

15.625 kHz

15.734 kHz

Pixel frequency

14.25 MHz

14.349949 MHz

CCD sensors

3 x 1/3” monochrome IT CCD

ICX-409AL-6

3 x 1/3” monochrome IT CCD

ICX-408AL-6

Sensing area

4.8 (h) x 3.6 (v) mm

Effective pixels

752 (h) x 582 (v)

768 (h) x 494 (v)

Pixels in video output

744 (h) x 575 (v)

765 (h) x 486 (v)

Cell size

6.5 (h) x 6.25 (v) µm

6.35 (h) x 7.4 (v) µm

Resolution horizontal

570 TV lines

Sensitivity (on sensor)

0.5 Lux, Max gain, 50% video

S/N ratio

54 dB

56 dB

Video outputs. (DC coupled)

RGB

Y/C PAL

VBS PAL

RGB

Y/C NTSC

VBS NTSC

Video output level

RGB and C signal, 0.7 Vpp, 75 Ω

G on sync, Y signal and Composite VS, 1.0 Vpp, 75 Ω

Gamma

1.0 - 0.45

Gain
Gain range

Manual – Automatic

0 to +18 dB

Accumulation

Field – Frame

Synchronization

Int. X-tal. Ext HD/VD or random trigger

Scanning

2:1 interlaced, non-interlaced

Composite VS input

1.0 Vpp ±0.3V. 75 Ω terminated

Composite sync output

4 Vpp from 75 Ω source

HD/VD sync input

4 Vpp ±2 V. (Termination TTL or 75 Ω)

HD/VD sync output

4 Vpp from 75 Ω source

Trigger input

4 Vpp ±2 V. (Termination TTL or 75 Ω)

WEN output (write enable)

4 Vpp from 75 Ω source

EEN output (exposure enable)

4 Vpp from 75 Ω source

Pixel clock output

4 Vpp from 75 Ω source

Shutter.

Continuous and Edge pre-select

(off), 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10,000 sec.

Pulse width control input

1 H to 900 H

Start/stop

1/10,000 to 1/77 second

Long time exposure

1 field to ∞

White balance

Manual, one push (2350 to 6400 K)

Functions controlled by
RS 232C

Trigger mode, Shutter speed, Accumulation, Interlace, AGC level, White clip,

Set-up, Manual gain, AGC/manual gain, Internal/ potentiometer gain set,

Gamma, white balance.

Functions controlled by internal DIP
switches

VD input/output, HD input/output

HD, VD and Trigger 75 Ω termination on/off

Operating temperature

-5°C to +45°C.

Humidity

20 - 80% non-condensing

Storage temp./humidity

-25°C to 60°C./20% - 90 % non-condensing

Vibration

3 G (15 Hz – 200 Hz in XYZ)

Shock

50 G

Regulations

CE (EN 50081-1, EN 50082-1) FCC part 15

Power

12V DC ± 10%. 6 W

Lens mount

C-mount. (Max 4.0 mm thread)

Dimensions

50 x 60 x 130 mm (HxWxD)

Weight

480 g
