JVC GR-D231 EN - Manual (Page 49)

EN
49
MasterPage: Ref_Heading0_Right
R
E
FE
RE
NCE
S
CAUTIONS
AC Adapter
When using the AC Adapter in areas other than the
USA
The provided AC Adapter features automatic voltage
selection in the AC range from 110 V to 240 V.
USING HOUSEHOLD AC PLUG ADAPTER
In case of connecting the unit’s power cord to an AC wall
outlet other than American National Standard C73 series
type use an AC plug adapter, called a “Siemens Plug”, as
shown.
For this AC plug adapter, consult your nearest JVC dealer.
Battery Packs
The supplied battery pack is a
lithium-ion battery. Before
using the supplied battery
pack or an optional battery
pack, be sure to read the
following cautions:
● To avoid hazards
... do not burn.
... do not short-circuit the
terminals. When transporting, make sure the provided
battery cap is attached to the battery. If the battery cap is
misplaced, carry the battery in a plastic bag.
... do not modify or disassemble.
... do not expose the battery to temperatures exceeding 60°C
(140°F), as this may cause the battery to overheat, explode
or catch fire.
... use only specified chargers.
● To prevent damage and prolong service life
... do not subject to unnecessary shock.
... charge in an environment where temperatures are within the
tolerances shown in the chart below. This is a chemical
reaction type battery — cooler temperatures impede
chemical reaction, while warmer temperatures can prevent
complete charging.
... store in a cool, dry place. Extended exposure to high
temperatures will increase natural discharge and shorten
service life.
... fully charge and then fully discharge the battery every 6
months when storing the battery pack over a long period
time.
... remove from charger or powered unit when not in use, as
some machines use current even when switched off.
NOTES:
● It is normal for the battery pack to be warm after charging, or
after use.
Temperature Range Specifications
Charging: 10°C to 35°C (50°F to 95°F)
Operation: 0°C to 40°C (32°F to 104°F)
Storage: –20°C to 50°C (–4°F to 122°F)
● The lower the temperature, the longer recharging takes.
● Charging times are for a fully discharged battery pack.
Cassettes
To properly use and store your cassettes, be sure to read
the following cautions:
● During use
... make sure the cassette bears the Mini DV mark.
... be aware that recording onto prerecorded tapes
automatically erases the previously recorded video and
audio signals.
... make sure the cassette is positioned properly when
inserting.
... do not load and unload the cassette repeatedly without
allowing the tape to run at all. This slackens the tape and can
result in damage.
... do not open the front tape cover. This exposes the tape to
fingerprints and dust.
● Store cassettes
... away from heaters or other heat sources.
... out of direct sunlight.
... where they won’t be subject to unnecessary shock or
vibration.
... where they won’t be exposed to strong magnetic fields (such
as those generated by motors, transformers or magnets).
... vertically, in their original cases.
Memory Cards
To properly use and store your memory cards, be sure to
read the following cautions:
● During use
... make sure the memory card bears the SD or
MultiMediaCard mark.
... make sure the memory card is positioned properly when
inserting.
● While the memory card is being accessed (during
recording, playback, deletion, initialization, etc.)
... never unload the memory card and never turn off the
camcorder.
● Store memory cards
... away from heaters or other heat sources.
... out of direct sunlight.
... where they won’t be subject to unnecessary shock or
vibration.
... where they won’t be exposed to strong magnetic fields (such
as those generated by motors, transformers or magnets).
LCD Monitor
● To prevent damage to the LCD monitor, DO NOT
... push it strongly or apply any shocks.
... place the camcorder with the LCD monitor on the bottom.
● To prolong service life
... avoid rubbing it with coarse cloth.
● Be aware of the following phenomena for LCD
monitor use. These are not malfunctions
... While using the camcorder, the surface around the LCD
monitor and/or the back of the LCD monitor may heat up.
... If you leave power on for a long time, the surface around the
LCD monitor becomes hot.
Main Unit
● For safety, DO NOT
... open the camcorder’s chassis.
... disassemble or modify the unit.
... short-circuit the terminals of the battery pack. Keep it away
from metallic objects when not in use.
... allow inflammables, water or metallic objects to enter the
unit.
... remove the battery pack or disconnect the power supply
while the power is on.
... leave the battery pack attached when the camcorder is not
in use.
● Avoid using the unit
... in places subject to excessive humidity or dust.
... in places subject to soot or steam such as near a cooking
stove.
... in places subject to excessive shock or vibration.
... near a television set.
Plug adapter
Terminals
CONTINUED ON NEXT PAGE
