JVC GR-D231 EN - Manual (Page 28)

MENUS FOR DETAILED ADJUSTMENT 28
EN
MasterPage: Left
[12 BIT]: Enables video recording of stereo sound on
four separate channels, and is recommended for use
when performing Audio Dubbing. (Equivalent to the 32
kHz mode of previous models)
16 BIT: Enables video recording of stereo sound on two
separate channels. (Equivalent to the 48 kHz mode of
previous models)
10X: When set to “10X” while using digital zoom, the
zoom magnification will reset to 10X since digital zoom
will be disengaged.
[40X]*: Allows you to use the Digital Zoom. By digitally
processing and magnifying images, zooming is possible
from 10X (the optical zoom limit), to a maximum of 40X
digital magnification.
500X*: Allows you to use the Digital Zoom. By digitally
processing and magnifying images, zooming is possible
from 10X (the optical zoom limit), to a maximum of 500X
digital magnification.
* Available only when the VIDEO/MEMORY Switch is set to
“VIDEO”.
[FULL]: Snapshot mode with no frame
NEGA: Nega mode
PIN-UP: Pin-Up mode
FRAME: Snapshot mode with frame
For details on the procedure, refer to “Snapshot (For
Video Recording)” (
੬ pg. 32).
OFF: Allows you to shoot dark scenes with no picture
brightness adjustment.
[AGC]: The overall appearance may be grainy, but the
image is bright.
AUTO
: The shutter speed is automatically
adjusted. Shooting a subject in low or poor lighting at
slow shutter speed provides a brighter image than in the
AGC mode, but the subject’s movements are not smooth
or natural. The overall appearance may be grainy. While
the shutter speed is being automatically adjusted, “
”
is displayed.
[MANUAL]: Enables thumbnail images to be made
manually. (
੬ pg. 36)
5SEC / 15SEC / 30SEC / 60SEC:
The captured image is stored in the memory card as a
thumbnail image when the recording time is over the
navigation time.
For example, “5SEC” is suitable to record short scenes
with the thumbnail images. (
੬ pg. 35) However, the
stored thumbnail images may take up a lot of memory. In
this case, using the memory card with large capacity is
recommended.
OFF: Disables the function.
● The “ ” indicator appears when “NAVIGATION” is
set to other than “MANUAL” and “OFF”.
MANUAL
The “q MANUAL” settings are effective only when the
Power Switch is set to “M”.
[ ] = Factory-preset
OFF: Disables the function.
[ON
]: To compensate for unstable images caused
by camera-shake, particularly at high magnification.
NOTES:
● Accurate stabilization may not be possible if hand shake is
excessive, or depending on the shooting condition.
● The “ ” indicator blinks or goes out if the Stabilizer
cannot be used.
● Switch off this mode when recording with the camcorder on
a tripod.
੬ pg. 31, “Self-Timer”
[OFF]: Disables 5-Second Recording.
5S: Enables 5-Second Recording. (
੬ pg. 32)
Anim.: Allows you to record a few frames only. By using
an inanimate object and changing its position between
shots, you can record the subject as though it is moving.
[OFF]: Disables the function.
ON: When the distance to the subject is less than 1 m
(3.3 ft), set “TELE MACRO” to “ON”. You can shoot a
subject as large as possible at a distance of approx.
60 cm (2 ft).
NOTE:
Depending on the zoom position, the lens may go out of focus.
SOUND MODE
ZOOM
SNAP MODE
GAIN UP
[FULL] PIN-UP FRAME NEGA
NAVIGATION
DIS
SELF-TIMER [OFF] / ON
5S
TELE MACRO
