FRONT DISPLAY PANEL
A “Timer” Indicator ੬ pg. 21
B Play Indicator
C Record Indicator
D Channel/Clock Display
To switch display, press – –:– –. Channel position is not
displayed during playback.
Mode Display (L-1)
E VCR Indicator ੬ pg. 17
ON-SCREEN DISPLAY
When “O.S.D.” is set to “ON” (
੬
pg. 27), various
operational indicators appear on the TV screen.
A Operation mode indicators
B Index MARK Indicator ੬ pg. 16
C Counter display ੬ pg. 18
D Tape remaining time indicator ੬ pg. 18
E Tape position indicator
The tape position indicator
appears on the TV screen
when you press
3 or
5 from the Stop mode
or perform an Index Search
(
੬
pg. 15). The position of
“ q ” in relation to “0”
(beginning) or “+” (end)
shows you where you are
on the tape.
NOTE:
Depending on the type of tape used, the tape position
indicator may not appear correctly.
F Current day/month/year
G Clock display
H Channel position number/
Auxiliary input indicator (L-1)
I Timer warning display
A warning appears on the TV screen to tell you that the timer-
recording is to start in 5 minutes if you’re not in the Timer
mode at that time.The warning blinks for the entire 5 minutes
leading up to the start of timer recording. To clear the display,
press
& .
J Cassette loaded mark
Beginning End
