Installation Instructions
OUO6050,0001293 –19–08SEP05–1/1
Install GreenStar Common Components
Install StarFire Receiver, GreenStar Display, Mobile
Processor, and GreenStar wiring harness (if needed).
(See GREENSTAR WIRING HARNESS AND STARFIRE
CAB BRACKET installation instructions.)
NOTE: If routing GreenStar harness through right-hand
console, connect AutoTrac Universal harness to
GreenStar harness before re-installing right-hand
console wrap. (See CONNECTING ATU
HARNESS TO GREENSTAR HARNESS section.)
OUO6050,000128D –19–20OCT05–1/2
Install AutoTrac Universal Steering Kit
PC8716
–UN–08SEP05
A—Locking Washer
B—Lock Nut
C—Telescoping Washers
D—Nut
1. Remove steering wheel from vehicle that will be
receiving the AutoTrac Universal Steering Kit. Retain
hardware (A-D) to be reinstalled when attaching
steering unit.
Continued on next page
PC20577 (22MAR06)
3
Installation Instructions
032206
PN=5
