Installation Instructions
OUO6050,00012B8 –19–14OCT05–1/2
Installing Angled Anti-Rotational Bracket
PC8753
–UN–08SEP05
Ex. - Large Frame JD7XX0, JD8XX0, JD9XX0
A—Anti-Rotation Bracket D—Lock Washer G—Telescoping Knob I—Telescoping Rod Nut
B—Steering Unit E—Nut H—Washer J—Cap
C—Screw (2 Used) F—Washer
Continued on next page
PC20577 (22MAR06)
9
Installation Instructions
032206
PN=11
