Specifications

Specifications

Specifications

Engine

444J

Manufacturer and Model . . . . . . . . . . . . . . . . . . . . John Deere PowerTech E

TM

4045H

Non-Road Emission Standards . . . . . . . . . . . . . . . . certified to EPA Tier 3 emissions
Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Valves Per Cylinder. . . . . . . . . . . . . . . . . . . . . . . . . 2
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276 cu. in. (4.5 L)
Net Peak Power (ISO9249) . . . . . . . . . . . . . . . . . . . 128 hp (95 kW) @ 2,000 rpm
Net Peak Torque (ISO9249). . . . . . . . . . . . . . . . . . . 380 lb.-ft. (515 Nm) @ 1,400 rpm
Net Torque Rise . . . . . . . . . . . . . . . . . . . . . . . . . . . 32%
Fuel System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . high-pressure common rail
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . full-flow spin-on filter and integral cooler
Aspiration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . turbocharged, charge air cooled
Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dual element dry type, restriction indicator in cab monitor for service
Fan Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulically driven, proportionally controlled, fan aft of coolers
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . 24 volt with 80-amp alternator
Batteries (two 12 volt) . . . . . . . . . . . . . . . . . . . . . . 950 CCA

Transmission

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . countershaft-type PowerShift

TM

Torque Converter . . . . . . . . . . . . . . . . . . . . . . . . . . single stage, single phase
Shift Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . electronically modulated, adaptive, load and speed dependent
Operator Interface . . . . . . . . . . . . . . . . . . . . . . . . . steering-column or hydraulic joystick-mounted F-N-R and gear-select lever, kick-down button on hydraulic lever
Shift Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . quick-shift button with two selectable modes: auto/manual, auto to 1st or 2nd, kick down or kick down/up, three clutch cutoff settings adjustable

on switch pad

Travel Speeds*

Forward

Reverse

Gear 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5 mph (7.2 km/h)

4.7 mph (7.6 km/h)

Gear 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.7 mph (12.4 km/h)

8.1 mph (13.0 km/h)

Gear 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14.9 mph (24.0 km/h)

15.7 mph (25.3 km/h)

Gear 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23.4 mph (37.7 km/h)

*Equipped with 17.5-25 tires.

Axles/Brakes

Final Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . heavy-duty mid-board planetary
Differentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulic locking front, conventional rear — standard; dual locking front and rear — optional
Rear Axle Oscillation, Stop to Stop* . . . . . . . . . . . . 24 deg.
Brakes (conform to SAE J1473, ISO3450)

Service Brakes . . . . . . . . . . . . . . . . . . . . . . . . hydraulically actuated, mid-board, self adjusting, wet multi-disc
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . automatic spring applied, hydraulically released, oil cooled, multi-disc

*Equipped with 17.5-25 tires.

Tires

Choice of (with three-piece rims)

Tread Width

Width Over Tires

Change In Vertical Height

17.5 R 25, L-3T. . . . . . . . . . . . . . . . . . . . . . . . 74.8 in. (1900 mm)

92.4 in. (2348 mm)

0 in. (0 mm)

17.5 R 25, L-2. . . . . . . . . . . . . . . . . . . . . . . . . 74.8 in. (1900 mm)

92.9 in. (2360 mm)

– 0.1 in. (– 3 mm)

17.5-25, 12 PR L-3 . . . . . . . . . . . . . . . . . . . . . 74.8 in. (1900 mm)

92.8 in. (2357 mm)

+ 0.1 in. (+ 3 mm)

17.5-25, L-2* . . . . . . . . . . . . . . . . . . . . . . . . . 74.8 in. (1900 mm)

92.8 in. (2357 mm)

+ 0.1 in. (+ 3 mm)

17.5-25, L-2 . . . . . . . . . . . . . . . . . . . . . . . . . . 74.8 in. (1900 mm)

92.8 in. (2357 mm)

+ 0.1 in. (+ 3 mm)

20.5-25, 12 PR L-2 . . . . . . . . . . . . . . . . . . . . . 76.8 in. (1950 mm)

98.1 in. (2492 mm)

+ 3.6 in. (+ 91 mm)

20.5-25, 1 Star L-2 Radial. . . . . . . . . . . . . . . . 76.8 in. (1950 mm)

97.7 in. (2482 mm)

+ 2.6 in. (+ 67 mm)

550/65 R 25, 1 Star L-2 . . . . . . . . . . . . . . . . . 76.8 in. (1950 mm)

98.0 in. (2490 mm)

+ 1.0 in. (+ 27 mm)

*Equipped with one-piece rims.

Refill Capacities (U.S.)

Fuel Tank (with ground-level fueling) . . . . . . . . . . . 65 gal. (246 L)
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 qt. (19 L)
Engine Oil with Vertical Spin-On Filter. . . . . . . . . . . 18.5 qt. (17.5 L)
