12 g.p.i. function led display – Intel 32882 User Manual
Page 52
47
4-12 G.P.I. Function LED Display
All LED off or glitter. It means the motherboard in the G.P.I mode. CPU works with the
low power consumption.
Three LED off or glitter. It means the motherboard is working on partial power saving
mode. (The LED off indicate the relative power phase working with idle mode).
Three LED on. It means the motherboard is working on partial power saving mode.
(The LED off indicate the relative power phase working with idle mode)
All LED on. It means the motherboard is working at full-speed with non- power saving
mode. CPU is working on high-load state.
PWS_LED2
PWS_LED3
PWS_LED4
PWS_LED1
PWS_LED2
PWS_LED4
PWS_LED1
PWS_LED2
PWS_LED3
PWS_LED4
PWS_LED1
PWS_LED2
PWS_LED3
PWS_LED4
PWS_LED1
PWS_LED3
