34
CPU Clock Skew
The optional settings are: Default; 100ps~1500ps.
DRAM Clock at Next Boot
The optional setting are: Auto; 800MHz (DDR3 800); 1066 MHz (DDR3 1066);
1333MHz (DDR3 1333).
Host/PCI Clock at Next Boot
Use the item to set CPU Frequency. Range between 133~500.
CPU Vcore 7-Shift
Use this item to set value in CPU Vcore 7-Shift function. optional settings are:
+50mV to 350mV.
CPU PLL Select
Use this tem to set CPU PLL from 1.816V (Default) to 2.043V.
PCH Core Voltage
Use this item to set PCH core voltage from the range of 1.079 (Default) to
1.180V.
CPU VTT Voltage
Use this item to set CPU VTT voltage from 1.140Vto 2.247V. The default value is
1.176v.
DRAM Voltage Select
Use this item to set DRAM voltage from 1.538V to 2.204V. The default value is
1.589v.
CPU AGX Voltage Select
The optional settings are: Auto, +50mV~+350 mV.
NOTICE! The voltage in BIOS settings is only for reference. If Voltage is set too
high, the color will change into red.
