BIOS SETUP
IB850 User’s Manual 53
PC Health Status
This section shows the parameters in determining the PC Health Status.
These parameters include temperatures, fan speeds and voltages.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
CPU Warning Temperature Disabled ITEM HELP
Current CPU Temp.
Current System Temp.
Current Chassis Temp.
CPU FAN Speed
System FAN Speed
Chassis FAN Speed
Vcore (V)
Menu Level >
+3.3V
+5V
+12V
-12V
VBAT(V)
5VSB(V)
Shutdown Temperature Disabled
CPU Fan Failure Warning Disabled
Sys. FAN Failure Warning Disabled
Cha. FAN Failure Warning Disabled
CPU Warning Temperature
This field allows the user to set the temperature so that when the
temperature is reached, the system sounds a warning. This function can
help prevent damage to the system that is caused by overheating.
Temperatures/Fan Speeds/Voltages
These fields are the parameters of the hardware monitoring function
feature of the CPU card. The values are read-only values as monitored by
the system and show the PC health status.
Shutdown Temperature
This field allows the user to set the temperature by which the system
automatically shuts down once the threshold temperature is reached. This
function can help prevent damage to the system that is caused by
overheating.
Temperature/CPU/Chassis Fan Failure Warning
When enabled, t his field lets the system sounds an audible warning to the
user that the CPU fan or chassis fan has malfunctioned.
