Page 15
INSTALLATIONS
IB850 User’s Manual
11
Jumper Locations on IB850
CN1
J1
DIMM1
J3
BZ1
DIMM2
JP8
J2
IDE1
FDD1
CN3
CN2
J8
J7
J9
AGP1
BAT1
IDE2
J6
J14
J4
J13
J11
J15
J5
J12
J19
RT2
JP7
J20
J21
Jumper Locations on IB850
JP1: Clear CMOS Contents
JP2, JP3, JP4: RS232/422/485
(COM2) Selection
JP6: 82551 10/100Mb LAN
Enable/Disable
JP7: DiskOnChip Address Select
JP9: AT/ATX Power Supply Select
