13
Insignia NS-20LCD Television
www.insignia-products.com
Specifications
Design and specifications are subject to change
without notice.
Accessories
• User guide
• AC cord
• Remote control
• 2 AAA batteries
Copyright
© 2006 Insignia. Insignia and the Insignia logo are
trademarks of Best Buy Enterprise Services, Inc. Other
brands and product names are trademarks or
registered trademarks of their respective holders.
Specifications and features are subject to change
without notice or obligation.
Picture lacks color or picture is
too dark • Make sure that the
color, brightness, and
contrast controls are
correctly adjusted.
All channels lose color
intermittently or there is snow • Make sure that the
antenna is connected.
• Make sure that the
antenna is not broken.
Picture wobbles or drifts • The station or cable
provider may be
experiencing
problems. Try a
different channel.
• The cable channel may
be scrambled. Contact
you cable provider for
a cable box.
• Check for local
interference.
No cable reception • Check all cable
connections.
• Contact your cable
provider regarding
possible service
interruption.
Television shuts off • Set the Sleep Timer to
off.
Closed captioning is not
working • Make sure that the
antenna or CATV
connector is
connected correctly.
• The station or cable
provider may be
experiencing
problems. Try a
different channel.
Parental control is not working • Parental control does
not work with news or
sporting events.
• Make sure that the
ratings are set
correctly.
Note
The LCD screen is manufactured to provide many years of
useful life. Occasionally a few non-active pixels may appear as
a fixed blue, green, or red point. This is not considered to be a
defect in the LCD screen.
Problem Solution
General
Diagonal display
size 20 inches
Television system NTSC
Channel coverage VHF: 2 ~ 13
UHF: 14 ~ 69
CATV: 2 ~ 13, A ~ W, W+1 ~ W+84, A-5 ~ A-1,
4A
Terminals
Antenna input VHF/UHF/CATV 75 ohm
S-Video input Y: 75 ohm 1.0Vp-p input
C: 75 ohm 0.286Vp-p input
Video input 75 ohm 1.0Vp-p input
Component video
input YPbPr/YCbCr Y:75 ohm 1.0Vp-p input
YPbPr/YCbCr: 75 ohm 1.0Vp-p input
(480P/60Hz,480i/60Hz,720P/60Hz,1080i/
60Hz)
VGA Analog RGB 15 pin x 1 75 ohm 0.70 Vp-p
input (640 x 480/60 Hz)
Video output VIDEO x 1
Audio input AV audio >10K ohm 1.0 Vrms input
Audio output AV audio x 1
Mini-jack for stereo (3.5) x 1
Other
Remote control Digital encoded infrared light system
Power requirements AC 120 V, 60 Hz
Power consumption
(Maximum) 55 W
Dimensions
(H x W x D) 24.6 x 18.1 x 11.8 inches
(625 x 460x 300 mm)
Weight 26 lbs. (11.8 kg)
