Press F11 to show the display that includes the type of service (TOS), maximum
transmission unit (MTU), type, and source.
Displaying Route Details Option
To display detailed information about the route:
1.
On the Display Associated Routes display, type 5 in the option field for each
route about which you want more information.
2. Press the Enter key.
Figure 37 on page 46 and Figure 38 on page 46 are examples.
Display Associated Routes
System: SYSNAM04
Interface internet address . . . . . . . . . : 9.125.87.10
Type options, press Enter.
5=Display details
Route Subnet Next Route
Opt Destination Mask Hop Available
9.125.87.0 255.255.255.0 *DIRECT*YES
*DFTROUTE *NONE 9.125.87.169 *YES
Bottom
F3=Exit F5=Refresh F6=Print list F11=Display route type F12=Cancel
F13=Sort by column F17=Top F18=Bottom
Figure 36. Associated Route Information, Display 1 of 2
Chapter 2. TCP/IP: Operation, Management, and Advanced Topics 45
