Chapter 5. IBM AFP Fonts for ASCII Data
When you specify a coded font name with the chars parameter of the acif
command or the line2afp command, the font name is limited to four characters,
excluding the two-character prefix.
| Figure 19 provides a list of the IBM Core Interchange Fonts for use with
| unformatted ASCII input data. Because these fonts have eight-character names, the
| table also provides a list of six-character short names. (Reminder: PSF for AIX
| must be installed if you want to use documented examples that contain pathnames
| indicating PSF.) These coded fonts are installed in the /usr/lpp/psf/reslib directory
| when the psf.acif installation option is installed for PSF 2.1 for AIX. However, for
| InfoPrint Manager, the ACIF component is installed automatically. The installation
| program also creates the symbolic links of the eight-character names that
| correspond to the six-character names. You may use these short names, without
| the X prefix, to satisfy the four-character limitation for specifying font names with
| the chars parameter.
Figure 19 (Page 1 of 2). Font Mapping Table for Use with the chars Parameter
Type Family
Point
Size
Coded Font
Name
Linked Short
Name (for chars
Parameter)
Courier 7 X0423072 X04272
Courier 8 X0423082 X04282
Courier 10 X0423002 X04202
Courier 12 X04230B2 X042B2
Courier 14 X04230D2 X042D2
Courier 20 X04230J2 X042J2
Helvetica 6 X0H23062 X0H262
Helvetica 7 X0H23072 X0H272
Helvetica 8 X0H23082 X0H282
Helvetica 9 X0H23092 X0H292
Helvetica 10 X0H23002 X0H202
Helvetica 11 X0H230A2 X0H2A2
Helvetica 12 X0H230B2 X0H2B2
Helvetica 14 X0H230D2 X0H2D2
Helvetica 16 X0H230F2 X0H2F2
Helvetica 18 X0H230H2 X0H2H2
Helvetica 20 X0H230J2 X0H2J2
Helvetica 24 X0H230N2 X0H2N2
Helvetica 30 X0H230T2 X0H2T2
Helvetica 36 X0H230Z2 X0H2Z2
Times New Roman 6 X0N23062 X0N262
Times New Roman 7 X0N23072 X0N272
