Icom IC-M505 - Manual (Page 44)

38
6
DSC OPERATION
When a GPS receiver (NMEA0183 ver. 2.0 or 3.01) is con-
nected, go to step y. Because the following steps (r and
t; Current position/time programming) do not appear.
r The position information appears. Set your position (lati-
tude and longitude) data by rotating [CHANNEL].
• Push [16•C] or [DIAL•DUAL/GRP] to move the cursor forward
or backward, respectively.
• Rotate [CHANNEL] to edit N; North latitude or S; South latitude
when the cursor is on the ‘N’ or ‘S’ position, and W; West longi-
tude or E; East longitude when the cursor is on the ‘W’ or ‘E’ po-
sition.
• Push [CLR] for 1 sec. to clear the latitude/longitude data.
• Push [CLR] to cancel and return to the DSC menu.
t After setting the position data, push [CHANNEL•ENTER]
to set the current UTC time. Set the current UTC time by
rotating [CHANNEL], then push [CHANNEL•ENTER].
• Push [16•C] or [DIAL•DUAL/GRP] to move the cursor forward
or backward, respectively.
• Push [CLR] for 1 sec. to clear the UTC time data.
• Push [CLR] to cancel and return to the DSC menu.
y Push [CHANNEL•ENTER] to transmit the position request
reply call to the selected station.
• Your position data is transmitted, when [CHANNEL•ENTER] is
pushed.
--DSC Menu--
Position Reply
Transmitting
--DSC Menu--
Input UTC Time
__:__ Null
1sec˘Null Null Data> Data>
Exit / ENT ENT˘OK> OK>
--DSC Menu--
Position Reply Ready
--DSC Menu--
Input Position
Latitude
__°__.___N Null
Longitude
__°__.___W Null
1sec˘Null Null Data> Data>
Exit / ENT ENT˘OK> OK>
