[MAIN UNIT]
6 - 5
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
C105
4030006860 S.CER C1608 JB 1H 102K-T
B
66.9/29
C106
4030006860 S.CER C1608 JB 1H 102K-T
T
68.3/30.4
C107
4030007050 S.CER C1608 CH 1H 220J-T
T
65.5/27.5
C111
4030007130 S.CER C1608 CH 1H 101J-T
T
64.1/26.2
C112
4030006860 S.CER C1608 JB 1H 102K-T
B
66.9/26.4
C113
4030011600 S.CER C1608 JB 1E 104K-T
B
69.7/26.4
C114
4030007090 S.CER C1608 CH 1H 470J-T
T
68.4/23.2
C115
4030006860 S.CER C1608 JB 1H 102K-T
T
68.4/20.3
C121
4030007100 S.CER C1608 CH 1H 560J-T
T
56.9/15.7
C122
4030006990 S.CER C1608 CH 1H 080D-T
T
55/12.7
C123
4030007030 S.CER C1608 CH 1H 150J-T
T
59.6/12.4
C124
4030006860 S.CER C1608 JB 1H 102K-T
T
55.7/10.5
C125
4030007030 S.CER C1608 CH 1H 150J-T
T
59.6/11.1
C126
4030007040 S.CER C1608 CH 1H 180J-T
T
62.8/8
C127
4030006860 S.CER C1608 JB 1H 102K-T
T
60.8/7.7
C128
4030007090 S.CER C1608 CH 1H 470J-T
T
67.5/16.3
C129
4030006860 S.CER C1608 JB 1H 102K-T
T
65.4/12.2
C131
4030006860 S.CER C1608 JB 1H 102K-T
T
66.2/6.5
C132
4030007050 S.CER C1608 CH 1H 220J-T
T
68.2/7.3
C133
4030011530 S.CER C1608 CH 1H 110J-T
T
65/9.7
C134
4030009650 S.CER C1608 CH 1H 240J-T
T
68.8/9.8
C135
4030006980 S.CER C1608 CH 1H 070D-T
T
68.2/12.2
C136
4030007000 S.CER C1608 CH 1H 090D-T
T
70.1/10
C137
4030006860 S.CER C1608 JB 1H 102K-T
B
66.1/3
C138
4030009510 S.CER C1608 CH 1H 010B-T
B
68.7/6.1
C141
4030011600 S.CER C1608 JB 1E 104K-T
B
70.4/16.9
C142
4030006860 S.CER C1608 JB 1H 102K-T
B
66.9/17.7
C143
4030011600 S.CER C1608 JB 1E 104K-T
B
69.1/22.6
C144
4030006900 S.CER C1608 JB 1H 103K-T
B
74/25.1
C145
4030006860 S.CER C1608 JB 1H 102K-T
B
67.6/34
C151
4030007000 S.CER C1608 CH 1H 090D-T
T
68.2/5.7
C152
4030007010 S.CER C1608 CH 1H 100D-T
T
62.3/2.9
C153
4030009530 S.CER C1608 CH 1H 030B-T
T
56.2/2.8
C154
4030006860 S.CER C1608 JB 1H 102K-T
B
61/7.9
C155
4030006860 S.CER C1608 JB 1H 102K-T
B
62.8/12.5
C156
4030011770 S.CER C1608 CH 1H 060B-T
B
59.5/5.9
C157
4030007060 S.CER C1608 CH 1H 270J-T
B
64/3.4
C158
4030006860 S.CER C1608 JB 1H 102K-T
B
65.5/5
C159
4030009550 S.CER C1608 CH 1H 2R5B-T
B
61.3/2.4
C160
4030009510 S.CER C1608 CH 1H 010B-T
B
56.7/3.2
C161
4030007100 S.CER C1608 CH 1H 560J-T
B
52.8/6.5
C162
4030006860 S.CER C1608 JB 1H 102K-T
B
55.6/11.4
C163
4030009910 S.CER C1608 CH 1H 040B-T
B
55.4/3.2
C164
4030006980 S.CER C1608 CH 1H 070D-T
T
53.6/3.4
C165
4030006900 S.CER C1608 JB 1H 103K-T
T
50.2/3.1
C166
4030007090 S.CER C1608 CH 1H 470J-T
T
48.9/3.1
C167
4030006900 S.CER C1608 JB 1H 103K-T
T
46.1/9
C168
4030011770 S.CER C1608 CH 1H 060B-T
T
58.9/5.6
C171
4030017480 S.CER C1608 JB 1A 474K-T
T
49.3/11.5
C172
4030006860 S.CER C1608 JB 1H 102K-T
T
52.2/5.9
C173
4030007090 S.CER C1608 CH 1H 470J-T
T
51.7/9.9
C181
4030006860 S.CER C1608 JB 1H 102K-T
T
47.3/6.5
C182
4030007120 S.CER C1608 CH 1H 820J-T
T
43.7/3.1
C183
4030006860 S.CER C1608 JB 1H 102K-T
T
43.7/11
C184
4030009550 S.CER C1608 CH 1H 2R5B-T
T
45.6/3.1
C185
4030009510 S.CER C1608 CH 1H 010B-T
T
43.7/5.1
C186
4030007070 S.CER C1608 CH 1H 330J-T
T
38.3/6.5
C187
4030006860 S.CER C1608 JB 1H 102K-T
T
37.9/8.4
C188
4030011770 S.CER C1608 CH 1H 060B-T
T
39.7/3.1
C189
4030009920 S.CER C1608 CH 1H 050B-T
T
38.4/3.1
C191
4030006860 S.CER C1608 JB 1H 102K-T
T
33.9/3.1
C192
4030007090 S.CER C1608 CH 1H 470J-T
T
31.9/3.8
C193
4030007100 S.CER C1608 CH 1H 560J-T
T
34.6/6.5
C194
4030008880 S.CER C1608 JB 1H 223K-T
T
31.5/9.3
C195
4030006860 S.CER C1608 JB 1H 102K-T
T
31.5/8
C201
4030006860 S.CER C1608 JB 1H 102K-T
B
50.6/6.9
C202
4030007060 S.CER C1608 CH 1H 270J-T
B
51.4/8.9
C203
4030006990 S.CER C1608 CH 1H 080D-T
B
40.7/6.6
C210 4550006300
S.TAN
ECST1AY475R
B 39.4/12
C211
4030006860 S.CER C1608 JB 1H 102K-T
B
34.9/9.8
C213
4030011770 S.CER C1608 CH 1H 060B-T
B
27.6/3.5
C215
4030006860 S.CER C1608 JB 1H 102K-T
B
26.6/10.3
C216
4030006900 S.CER C1608 JB 1H 103K-T
B
24.7/8.6
C217
4030007130 S.CER C1608 CH 1H 101J-T
B
19.8/7.1
C221
4030007010 S.CER C1608 CH 1H 100D-T
B
32.4/28.1
C222
4030006900 S.CER C1608 JB 1H 103K-T
B
30.9/23.1
C223
4030007040 S.CER C1608 CH 1H 180J-T
B
31.3/16.3
C224
4030009520 S.CER C1608 CH 1H 020B-T
B
29.8/17.6
C225
4030007040 S.CER C1608 CH 1H 180J-T
B
28.1/15.3
C226
4030007010 S.CER C1608 CH 1H 100D-T
B
20.7/16.2
C231
4030006860 S.CER C1608 JB 1H 102K-T
T
15.5/8.2
C232
4030007130 S.CER C1608 CH 1H 101J-T
T
20.1/10.9
C233
4030011600 S.CER C1608 JB 1E 104K-T
B
9.8/8.5
C234
4030011600 S.CER C1608 JB 1E 104K-T
B
9.8/13.7
C235
4030011600 S.CER C1608 JB 1E 104K-T
B
7.9/16
C236
4030006900 S.CER C1608 JB 1H 103K-T
B
11.1/10.5
C237
4030007140 S.CER C1608 CH 1H 121J-T
T
13.5/12
C238
4030007140 S.CER C1608 CH 1H 121J-T
T
11.5/13.1
C239 4550006300
S.TAN
ECST1AY475R
T 11.5/9.3
C240
4030006860 S.CER C1608 JB 1H 102K-T
B
12.4/9.3
C241
4030011600 S.CER C1608 JB 1E 104K-T
B
12.4/13.8
C242
4030006860 S.CER C1608 JB 1H 102K-T
T
17.4/14.9
C243
4030006860 S.CER C1608 JB 1H 102K-T
T
17.5/12.3
C244
4030006860 S.CER C1608 JB 1H 102K-T
T
20.7/13.6
C245
4030006860 S.CER C1608 JB 1H 102K-T
B
22.7/14.1
C246
4030011340 S.CER C1608 CH 1H 471J-T
B
16.2/16.7
[MAIN UNIT]
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
C247
4030006860 S.CER C1608 JB 1H 102K-T
T
17.4/11
C251
4030006900 S.CER C1608 JB 1H 103K-T
B
5.3/17
C252
4030006900 S.CER C1608 JB 1H 103K-T
B
12.3/19.3
C253
4030006900 S.CER C1608 JB 1H 103K-T
B
12.3/25.1
C261
4030008860 S.CER C1608 JB 1H 153K-T
[US1] only T
24.9/24.7
C262
4030008900 S.CER C1608 JB 1H 333K-T
T
22.1/23.3
C263
4030008920 S.CER C1608 JB 1H 473K-T
T
21.3/25.3
C265
4030006860 S.CER C1608 JB 1H 102K-T
T
14.9/29.3
C266
4030007150 S.CER C1608 CH 1H 151J-T
T
20.3/31.2
C267
4030006880 S.CER C1608 JB 1H 472K-T
T
24.9/32.5
C268
4030008920 S.CER C1608 JB 1H 473K-T
T
14.4/31.7
C269
4030006900 S.CER C1608 JB 1H 103K-T
T
13.6/24.7
C270
4030017490 S.CER C1608 JB 1A 105K-T
T
15.9/32.5
C271 4550006950
S.TAN
ECST0JX476R
B
40.7/40.4
C272
4030017480 S.CER C1608 JB 1A 474K-T
T
20/16.1
C281
4030006900 S.CER C1608 JB 1H 103K-T
T
22.1/20.4
C282
4030006900 S.CER C1608 JB 1H 103K-T
B
70.5/31
C291
4030006900 S.CER C1608 JB 1H 103K-T
T
32.2/17
C292
4030009880 S.CER C1608 JB 1H 682K-T
T
26.9/16.3
C293
4030008900 S.CER C1608 JB 1H 333K-T
T
28.9/19.7
C294
4030009970 S.CER C1608 JB 1H 182K-T
T
27.6/23.8
C301
4030008880 S.CER C1608 JB 1H 223K-T
T
31.6/26.2
C302
4030006870 S.CER C1608 JB 1H 222K-T
T
28.6/28.5
C311
4030006860 S.CER C1608 JB 1H 102K-T
B
25.4/17.4
C312
4030008880 S.CER C1608 JB 1H 223K-T
B
28.9/24.3
C313
4030009490 S.CER C1608 JB 1H 821K-T
B
23.5/24.3
C314
4030009490 S.CER C1608 JB 1H 821K-T
B
19.8/18.1
C315
4030011600 S.CER C1608 JB 1E 104K-T
B
28.4/21
C316
4030008920 S.CER C1608 JB 1H 473K-T
B
21.8/19.9
C322
4030006900 S.CER C1608 JB 1H 103K-T
T
51.3/41.6
C323
4030006900 S.CER C1608 JB 1H 103K-T
T
56/41
C324
4030006900 S.CER C1608 JB 1H 103K-T
T
58/41.6
C325 4550006710
S.TAN
ECST1AX226R
B
58.9/39.4
C326 4550006300
S.TAN
ECST1AY475R
T
60.8/39.5
C327 4550006300
S.TAN
ECST1AY475R
B
25.3/41.1
C333
4030006860 S.CER C1608 JB 1H 102K-T
B
46.5/41.9
C341
4030006900 S.CER C1608 JB 1H 103K-T
B
12.3/22.3
C381
4030017490 S.CER C1608 JB 1A 105K-T
B
11.8/29.2
C382
4030017490 S.CER C1608 JB 1A 105K-T
B
10.1/39.7
C383
4030017490 S.CER C1608 JB 1A 105K-T
B
11.9/41
C384
4030011600 S.CER C1608 JB 1E 104K-T
B
5/37.3
C385
4030011600 S.CER C1608 JB 1E 104K-T
B
9.2/41.3
C386
4030017490 S.CER C1608 JB 1A 105K-T
B
10.4/29.4
C387
4030017490 S.CER C1608 JB 1A 105K-T
B
8.4/30.6
C388
4030006900 S.CER C1608 JB 1H 103K-T
B
4.3/34
C389
4030006900 S.CER C1608 JB 1H 103K-T
B
4.3/30
C391
4030011600 S.CER C1608 JB 1E 104K-T
B
26.3/39.3
C392
4030007060 S.CER C1608 CH 1H 270J-T
T
21.7/35.1
C393
4030007060 S.CER C1608 CH 1H 270J-T
T
21.1/37
C394
4030007140 S.CER C1608 CH 1H 121J-T
T
13/38.2
C395
4030011600 S.CER C1608 JB 1E 104K-T
T
13.6/33.8
C396
4030017490 S.CER C1608 JB 1A 105K-T
T
13.1/31.5
C397
4030017490 S.CER C1608 JB 1A 105K-T
T
15.1/27.5
C398
4030007020 S.CER C1608 CH 1H 120J-T
T
23.8/37
J281 6510023540
CNR
B2B-PH-K-S
J351 6510023520
S.CNR
54104-3692
T
7.4/28.1
F281 5210000830
S.FUS
ERBFE3R00U
T
75.3/23.9
W40 7030003860
S.RES
ERJ3GE
JPW
V
B
37.6/31.8
W91 7030003860
S.RES
ERJ3GE
JPW
V
B
51.4/19.3
W92 7030003860
S.RES
ERJ3GE
JPW
V
B
51.4/22.1
W101 7030003860
S.RES
ERJ3GE
JPW
V
B 53.2/29.3
W102 7030003860
S.RES
ERJ3GE
JPW
V
B 52.7/32.1
W201 7030003860
S.RES
ERJ3GE
JPW
V
B 45.8/8.9
W202 7030003860
S.RES
ERJ3GE
JPW
V
B 42.9/8.9
EP1
0910055971 PCB
B 5933A
EP2 6910012350
S.BEA
MMZ1608Y
102BT
B
28.6/39.3
EP3 6910012350
S.BEA
MMZ1608Y
102BT
B
28.8/37.3
EP101 6910013370
S.BEA
BLM18BB221SN1D
T 69.7/23.2
EP111 6910014690
S.BEA
MPZ1608S221A-T
T 71.3/20.3
US=USA, US1=USA−1 S.=Surface mount
