[VR UNIT]
US=USA, US1=USA−1 S.=Surface mount
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
R801 7210003130 VAR TP76N97N-13F-10KA-2497
W801 8900011900
CBL OPC-1192
W802 8900011910 CBL OPC-1193 [US], [SEA]
8900012031 CBL OPC-1231A [US1]
EP801
0910055622 PCB B 5892B [US], [SEA]
0910055991 PCB B 5982A [US1]
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
Q552 1590001190 S.TR XP6501-(TX) .AB B 13.3/23.7
Q553 1590000430 S.TR DTC144EUA T106 B 20.1/20.1
Q561 1510000670 S.TR 2SA1588-GR (TE85R) B 22/16
Q651 1590001770 S.TR XP1213 (TX) B 27.4/16.9
D451 1730002360
S.ZEN MA8062-M (TX) T 57/13.4
D452 1790000950 S.ZEN MA8056-M (TX) T 63.8/13.7
D453 1790000950 S.ZEN MA8056-M (TX) T 61.9/14
D454 1790000950 S.ZEN MA8056-M (TX) T 60/15.2
D581 1790001250 S.DIO MA2S111-(TX) B 48.8/40.1
D601 1790000620 S.DIO MA77 (TX) B 47.1/36.1
X601
6050011550 S.XTL CR-747 (9.8304 MHz) B 41.4/42.1
L421 6200010230
S.COL EXCCL3216U1 B 32.4/40.8
R411
7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 62.9/42.5
R412 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 60/40.2
R413 7030003620 S.RES ERJ3GEYJ 333 V (33 k Ω) T 56.5/40.3
R414 7030003820 S.RES ERJ3GEYJ 155 V (1.5 M Ω) T 54.3/43.1
R415 7030003820 S.RES ERJ3GEYJ 155 V (1.5 M Ω) B 6.4/17.6
R421 7030003260 S.RES ERJ3GEYJ 330 V (33 Ω) B 19.7/44.7
R422 7030003200 S.RES ERJ3GEYJ 100 V (10 Ω) B 30.7/40.6
R431 7030003610 S.RES ERJ3GEYJ 273 V (27 k Ω) B 16.5/42.1
R432 7030003800 S.RES ERJ3GEYJ 105 V (1 M Ω) B 16.5/43.4
R433 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k Ω) B 3.5/43.5
R434 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k Ω) B 6.7/46.3
R435 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k Ω) B 3.9/46.2
R441 7030003760 S.RES ERJ3GEYJ 474 V (470 k Ω) T 49.5/30.7
R442 7030003760 S.RES ERJ3GEYJ 474 V (470 k Ω) T 51.9/26.6
R443 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) T 57.4/28.7
R451 7030003280 S.RES ERJ3GEYJ 470 V (47 Ω) T 51.9/16.4
R452 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) T 55.4/14.2
R453 7410000950 S.ARY EXB-V8V 102JV T 61.9/10.4
R454 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 55.3/17.5
R461 7030003620 S.RES ERJ3GEYJ 333 V (33 k Ω) B 54.5/9.8
R462 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 44.6/9.8
R463 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k Ω) B 41/9.8
R464 7030003580 S.RES ERJ3GEYJ 153 V (15 k Ω) B 60.9/11
R465 7030003690 S.RES ERJ3GEYJ 124 V (120 k Ω) B 59/10.4
R466 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 57.7/10.4
R467 7030003400 S.RES ERJ3GEYJ 471 V (470 Ω) B 53.5/14.4
R468 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 55.7/15.7
R470 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 52/10.9
R471 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 41/7
R472 7030003590 S.RES ERJ3GEYJ 183 V (18 k Ω) B 36.7/8.9
R473 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 39.7/7
R474 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 37.6/7.2
R475 7030010290 S.RES ERJ3GEYF 273 V (27 k Ω) B 36.4/10.2
R476 7030004740 S.RES ERJ3GEYF 392 V (3.9 k Ω) B 30.9/7.8
R477 7030004730 S.RES ERJ3GEYF 222 V (2.2 k Ω) B 35.6/6.7
R478 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 52.2/14.2
R481 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 28.6/6.2
R482 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 24.7/5.3
R491 7030003580 S.RES ERJ3GEYJ 153 V (15 k Ω) B 14.9/4.3
R492 7030003720 S.RES ERJ3GEYJ 224 V (220 k Ω) B 13.4/8.5
R493 7030003770 S.RES ERJ3GEYJ 564 V (560 k Ω) B 11.1/5.9
R494 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 11.8/3.9
R495 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 13.1/5.6
R496 7030003720 S.RES ERJ3GEYJ 224 V (220 k Ω) B 9.8/10
R497 7030003710 S.RES ERJ3GEYJ 184 V (180 k Ω) B 16.8/11.6
R498 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 16.1/8.8
R501 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 10.6/7.8
R502 7030003620 S.RES ERJ3GEYJ 333 V (33 k Ω) B 8.2/9.5
R503 7030003690 S.RES ERJ3GEYJ 124 V (120 k Ω) B 6.9/9.5
R504 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 4.9/8.7
R511 7030003610 S.RES ERJ3GEYJ 273 V (27 k Ω) B 12.9/10.4
R512 7030003700 S.RES ERJ3GEYJ 154 V (150 k Ω) B 11.1/10
R513 7030003590 S.RES ERJ3GEYJ 183 V (18 k Ω) B 14.2/14.4
R521 7030003420 S.RES ERJ3GEYJ 681 V (680 Ω) B 4.9/10.2
R531 7030003600 S.RES ERJ3GEYJ 223 V (22 k Ω) B 10/16
R532 7030003600 S.RES ERJ3GEYJ 223 V (22 k Ω) B 9/12.5
R533 7030003650 S.RES ERJ3GEYJ 563 V (56 k Ω) B 8.5/13.8
R534 7030003710 S.RES ERJ3GEYJ 184 V (180 k Ω) B 8.4/16.2
R535 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 17.1/5.8
R536 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 19.1/5.2
R537 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 19.1/6.5
R538 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) B 23.2/13.6
R539 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 19.9/8.5
R540 7030003580 S.RES ERJ3GEYJ 153 V (15 k Ω) B 20.1/11.3
R551 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 18.1/26.3
R552 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k Ω) B 14.4/20.2
J851 6910014800 CNR IMSA-9230B-1-09Z133-T [US], [SEA]
6910015030 CNR IMSA-9230B-1-09Z135-T [US1]
EP851
0910055631 PCB B 5893A [US], [SEA]
0910055632 PCB B 5893B [US1]
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
IC421 1110001810 S.IC TA7368F (ER) B 24.8/41.8
IC471 1110003800 S.IC NJM2904V-TE1 B 46.2/7.1
IC481 1130007300 S.IC TC4W66FU (TE12L) B 26.1/8.6
IC491 1110003800 S.IC NJM2904V-TE1 B 6.5/4.7
IC551 1110005350 S.IC NJM2870F05-TE1 B 12.6/39.7
IC581 1110005770 S.IC S-80942CNMC-G9C-T2 B 51.3/41
IC591 1130010390 S.IC HN58X2416TI T 51.2/40.6
IC661 1140011150 S.IC µPD780316GC-511-9EB 2600A B 36/24.7
IC681 1130007300 S.IC TC4W66FU (TE12L) B 43.1/12.7
Q411 1530003090
S.TR 2SC4213-B (TE85R) T 62.2/40.6
Q431 1520000450 S.TR 2SB1132 T100 Q B 11.7/45.3
Q432 1590001190 S.TR XP6501-(TX) .AB B 6.9/44.4
Q441 1530002850 S.TR 2SC4116-BL (TE85R) T 51.8/28.5
Q442 1560001130 S.FET CPH3403-TL T 55/28
Q443 1560001130 S.FET CPH3403-TL B 57.8/29.4
Q444 1590000430 S.TR DTC144EUA T106 B 59.6/32.3
Q461 1590003430 S.TR UNR911HJ-(TX) B 56.1/13.8
Q462 1590003420 S.TR UNR911FJ-(TX) B 58.2/13.6
Q501 1590000430 S.TR DTC144EUA T106 B 11.9/15.9
Q531 1590001770 S.TR XP1213 (TX) B 17.9/14.6
Q532 1530002850 S.TR 2SC4116-BL (TE85R) B 22/11.4
Q551 1520000450 S.TR 2SB1132 T100 Q B 17.1/22.9
[CONNECTOR UNIT]
[LOGIC UNIT]
[LOGIC UNIT]
