[MAIN UNIT]
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
R112 7030003200
S.RES
ERJ3GEYJ
100
V
(10
Ω)
T
66.9/24.7
R113 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
B
68.4/24.8
R114 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
66.9/23.5
R121 7030003580
S.RES
ERJ3GEYJ
153
V
(15
k
Ω)
B
67/13.3
R122 7030000280
S.RES
MCR10EZHJ
150
Ω (151)
T
65.3/17.5
R131 7030003670
S.RES
ERJ3GEYJ
823
V
(82
k
Ω)
T
70.1/12.9
R132 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
66.8/5
R133 7030003580
S.RES
ERJ3GEYJ
153
V
(15
k
Ω)
B
67.8/7.4
R141 7030003700
S.RES
ERJ3GEYJ
154
V
(150
k
Ω)
B
69.1/16.9
R142 7030003630
S.RES
ERJ3GEYJ
393
V
(39
k
Ω)
B
72.4/17.1
R143 7030003480
S.RES
ERJ3GEYJ
222
V
(2.2
k
Ω)
B
70.4/19.7
R144 7030003490
S.RES
ERJ3GEYJ
272
V
(2.7
k
Ω)
B
69.1/19.7
R145 7030003570
S.RES
ERJ3GEYJ
123
V
(12
k
Ω)
B
66.5/21.5
R146 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
67.8/21.1
R147 7030003700
S.RES
ERJ3GEYJ
154
V
(150
k
Ω)
B
70.4/22.6
R148 7030003320
S.RES
ERJ3GEYJ
101
V
(100
Ω)
B
71.2/25.1
R149 7030003440
S.RES
ERJ3GEYJ
102
V
(1
k
Ω)
B
69.6/29
R151 7030003320
S.RES
ERJ3GEYJ
101
V
(100
Ω)
B
60.8/9.9
R152 7030003600
S.RES
ERJ3GEYJ
223
V
(22
k
Ω)
B
59.6/11.2
R153 7030003720
S.RES
ERJ3GEYJ
224
V
(220
k
Ω)
B
63.5/6
R154 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
65.8/7.8
R155 7030003720
S.RES
ERJ3GEYJ
224
V
(220
k
Ω)
B
54.2/9.4
R156 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
55.7/9.4
R165 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
51.8/7.9
R166 7030003730
S.RES
ERJ3GEYJ
274
V
(270
k
Ω)
T
51.5/3.1
R167 7030003400
S.RES
ERJ3GEYJ
471
V
(470
Ω)
T
47.6/3.1
R171 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
47.7/14.1
R172 7030003760
S.RES
ERJ3GEYJ
474
V
(470
k
Ω)
T
53/9.9
R173 7030003530
S.RES
ERJ3GEYJ
562
V
(5.6
k
Ω)
T
52.9/13.4
R175 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
49.8/9.4
R181 7030003430
S.RES
ERJ3GEYJ
821
V
(820
Ω)
T
46.5/5.1
R182 7030003720
S.RES
ERJ3GEYJ
224
V
(220
k
Ω)
T
43.7/8.4
R183 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
43.7/9.7
R184 7030003720
S.RES
ERJ3GEYJ
224
V
(220
k
Ω)
T
40.7/7.8
R185 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
40.7/9.1
R186 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
T
36.1/2.6
R191 7030003330
S.RES
ERJ3GEYJ
121
V
(120
Ω)
T
31.2/5.9
R192 7030003320
S.RES
ERJ3GEYJ
101
V
(100
Ω)
T
35.3/11.1
R193 7030003500
S.RES
ERJ3GEYJ
332
V
(3.3
k
Ω)
T
32.6/5.9
R201 7030003440
S.RES
ERJ3GEYJ
102
V
(1
k
Ω)
B
49.5/11.8
R202 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
51.4/10.2
R203 7030003400
S.RES
ERJ3GEYJ
471
V
(470
Ω)
B
49.2/6.9
R204 7030003210
S.RES
ERJ3GEYJ
120
V
(12
Ω)
B
48.6/8.9
R205 7030003400
S.RES
ERJ3GEYJ
471
V
(470
Ω)
B
47.5/6.9
R206 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
B
38.6/5.1
R211 7030003440
S.RES
ERJ3GEYJ
102
V
(1
k
Ω)
B
35.9/8.5
R213 7030003460
S.RES
ERJ3GEYJ
152
V
(1.5
k
Ω)
B
23.3/4.3
R214 7030003400
S.RES
ERJ3GEYJ
471
V
(470
Ω)
B
22.8/8.9
R215 7030003690
S.RES
ERJ3GEYJ
124
V
(120
k
Ω)
B
22.9/5.6
R216 7030003420
S.RES
ERJ3GEYJ
681
V
(680
Ω)
B
21.8/6.9
R221 7030003780
S.RES
ERJ3GEYJ
684
V
(680
k
Ω)
B
32.2/23.1
R222 7030003450
S.RES
ERJ3GEYJ
122
V
(1.2
k
Ω)
T
32.9/19.6
R223 7030003340
S.RES
ERJ3GEYJ
151
V
(150
Ω)
T
15.5/9.6
R231 7030003500
S.RES
ERJ3GEYJ
332
V
(3.3
k
Ω)
T
22.1/10.2
R232 7030003280
S.RES
ERJ3GEYJ
470
V
(47
Ω)
T
25/9.2
R233 7030003580
S.RES
ERJ3GEYJ
153
V
(15
k
Ω)
B
3.4/6.4
R234 7030003600
S.RES
ERJ3GEYJ
223
V
(22
k
Ω)
B
7/9
R235 7030003600
S.RES
ERJ3GEYJ
223
V
(22
k
Ω)
B
8.5/13.5
R236 7030004040
S.RES
ERJ3GEYJ
4R7
V
(4.7
Ω)
B
4.9/11
R237 7030003570
S.RES
ERJ3GEYJ
123
V
(12
k
Ω)
B
4.7/15.7
R238 7030003580
S.RES
ERJ3GEYJ
153
V
(15
k
Ω)
B
11.1/13.4
R239 7030003720
S.RES
ERJ3GEYJ
224
V
(220
k
Ω)
T
14.3/14
R240 7030003640
S.RES
ERJ3GEYJ
473
V
(47
k
Ω)
T
9.8/13.1
R241 7030003540
S.RES
ERJ3GEYJ
682
V
(6.8
k
Ω)
T
10.7/11.1
R242 7030003390
S.RES
ERJ3GEYJ
391
V
(390
Ω)
T
17.5/13.6
R243 7030004040
S.RES
ERJ3GEYJ
4R7
V
(4.7
Ω)
B
9.8/10.9
R244 7030003480
S.RES
ERJ3GEYJ
222
V
(2.2
k
Ω)
B
20.7/14.9
R245 7030003640
S.RES
ERJ3GEYJ
473
V
(47
k
Ω)
B
14.1/15.8
R246 7030003640
S.RES
ERJ3GEYJ
473
V
(47
k
Ω)
B
14.2/17.3
R251 7030003400
S.RES
ERJ3GEYJ
471
V
(470
Ω)
B
12.7/27.2
R261 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω) [US1] only T
24.9/26
R262 7030003570
S.RES
ERJ3GEYJ
123
V
(12
k
Ω)
T
22.6/25.3
R263 7030003640
S.RES
ERJ3GEYJ
473
V
(47
k
Ω)
T
25.8/29.9
R264 7030003550
S.RES
ERJ3GEYJ
822
V
(8.2
k
Ω)
T
24.6/28.6
R265 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
22.6/28.1
R266 7030003530
S.RES
ERJ3GEYJ
562
V
(5.6
k
Ω)
T
21.3/28.1
R267 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
24.6/27.3
R269 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
13.1/26.6
R270 7030003580
S.RES
ERJ3GEYJ
153
V
(15
k
Ω)
T
22.2/30.4
R271 7030003650
S.RES
ERJ3GEYJ
563
V
(56
k
Ω)
T
24.9/31.2
R272 7030003700
S.RES
ERJ3GEYJ
154
V
(150
k
Ω)
T
22.2/31.7
R273 7030003440
S.RES
ERJ3GEYJ
102
V
(1
k
Ω)
T
18.5/32.5
R274 7030003480
S.RES
ERJ3GEYJ
222
V
(2.2
k
Ω) [US1] only T
17.2/32.5
R275 7030003710
S.RES
ERJ3GEYJ
184
V
(180
k
Ω)
T
15.6/24.9
R276 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
13.1/21.4
R277 7030003750
S.RES
ERJ3GEYJ
394
V
(390
k
Ω)
T
13.4/18.6
R278
7030010290 S.RES ERJ3GEYF 273 V (27 k
Ω)
T
42.4/38.5
R279
7030004910 S.RES ERJ3GEYF 332 V (3.3 k
Ω)
T
42.4/37.2
R280
7030004730 S.RES ERJ3GEYF 222 V (2.2 k
Ω)
T
42.4/39.8
R281 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
18.7/16.9
R283 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
22.1/22
R284 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
22/16.8
[MAIN UNIT]
R291
7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω)
T
25.4/15
R292
7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω)
T
28.2/17.6
R293
7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω)
T
27.6/21
R294 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
30.9/18.8
R296
7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω)
T
31.5/20.8
R297 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
31.4/23.7
R298 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
T
28.6/27.2
R305 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
T
30.2/20.8
R306
7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω)
T
32.7/23.7
R307 7030003450
S.RES
ERJ3GEYJ
122
V
(1.2
k
Ω)
T
28.6/25.9
R311 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
27.4/25.6
R312 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
28.9/23
R313
7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω)
B
26.2/24
R314
7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω)
B
23.5/23
R315
7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω)
B
27/19.8
R316
7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω)
B
26.2/22.7
R317
7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω)
B
21.5/22.6
R321 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
51.4/39.5
R322 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
T
42.4/35.9
R323 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
54/41.6
R324 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
T
52.9/37.1
R325 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
58/40.3
R326 7030003520
S.RES
ERJ3GEYJ
472
V
(4.7
k
Ω)
T
55.1/36.6
R336 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
46.4/39.9
R381 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
B
6.5/41.3
R382
7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω)
B
7.1/39.8
R383 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
4.3/35.3
R384
7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω)
B
8.4/28
R385 7030003500
S.RES
ERJ3GEYJ
332
V
(3.3
k
Ω)
B
8.4/29.3
R386 7030003680
S.RES
ERJ3GEYJ
104
V
(100
k
Ω)
B
4.7/32
R387
7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω)
T
20.4/35.1
R388 7030003440
S.RES
ERJ3GEYJ
102
V
(1
k
Ω)
T
23.2/35
R389 7030003560
S.RES
ERJ3GEYJ
103
V
(10
k
Ω)
T
25.8/37.7
C1
4030011600 S.CER C1608 JB 1E 104K-T
B
28.6/30.8
C2
4030011600 S.CER C1608 JB 1E 104K-T
B
30.4/26.7
C3
4030006860 S.CER C1608 JB 1H 102K-T
B
30.4/28
C4
4030007090 S.CER C1608 CH 1H 470J-T
B
26.4/27.6
C5
4030011600 S.CER C1608 JB 1E 104K-T
B
28.6/42
C6 4550006560
S.TAN
ECST1CY225R
T
27.5/38.6
C7
4030006900 S.CER C1608 JB 1H 103K-T
T
30.6/40.9
C8
4030007130 S.CER C1608 CH 1H 101J-T
T
32.3/39.6
C9
4030007000 S.CER C1608 CH 1H 090D-T
T
32.5/41.6
C10
4030011600 S.CER C1608 JB 1E 104K-T
T
40.8/41.3
C11
4030007130 S.CER C1608 CH 1H 101J-T
T
35.2/38.4
C12
4030007130 S.CER C1608 CH 1H 101J-T
T
37.8/36.7
C13
4030007090 S.CER C1608 CH 1H 470J-T
T
35.8/37.1
C14
4030006860 S.CER C1608 JB 1H 102K-T
B
35.2/26.9
C16 4550006300
S.TAN
ECST1AY475R
B
41.7/35.7
C17 4550006160
S.TAN
ECST1CY155R
B
46.7/35.9
C19
4030006860 S.CER C1608 JB 1H 102K-T
T
31.7/28.4
C20
4030006860 S.CER C1608 JB 1H 102K-T
T
32.6/32.6
C21
4030006860 S.CER C1608 JB 1H 102K-T
T
2.7/27.6
C31
4030009990 S.CER C1608 CH 1H 200J-T
T
41.6/32.7
C32
4030007000 S.CER C1608 CH 1H 090D-T
T
42.9/27
C33
4030007080 S.CER C1608 CH 1H 390J-T
T
41.6/24.9
C34
4030006860 S.CER C1608 JB 1H 102K-T
B
37.7/16.2
C35
4030011340 S.CER C1608 CH 1H 471J-T
B
39.1/14.7
C36
4030017490 S.CER C1608 JB 1A 105K-T
B
34.6/16
C37
4030009540 S.CER C1608 CH 1H 1R5B-T
B
42.2/19.8
C41
4030009920 S.CER C1608 CH 1H 050B-T
[US1] only T
45.4/31.9
C42
4030007090 S.CER C1608 CH 1H 470J-T
T
45.7/30.6
C43
4030007020 S.CER C1608 CH 1H 120J-T
T
49.7/29.6
C44
4030011340 S.CER C1608 CH 1H 471J-T
T
51.8/31.6
C45
4030006900 S.CER C1608 JB 1H 103K-T
T
51.8/32.9
C46
4030009560 S.CER C1608 CH 1H R75B-T
T
51.7/30.3
C47 4550006700
S.TAN
ECST1AY106R
T
45.1/41.5
C48 4550006700
S.TAN
ECST1AY106R
T
48.8/40.6
C49
4030007050 S.CER C1608 CH 1H 220J-T
B
52.1/37.2
C51
4030009560 S.CER C1608 CH 1H R75B-T
T
38.5/20.8
C52
4030011770 S.CER C1608 CH 1H 060B-T
T
40.5/22.1
C53
4030007050 S.CER C1608 CH 1H 220J-T
T
46.7/24.7
C54
4030007040 S.CER C1608 CH 1H 180J-T
T
48.7/24.4
C55
4030011340 S.CER C1608 CH 1H 471J-T
T
51.7/29
C56
4030006900 S.CER C1608 JB 1H 103K-T
T
51.7/27.6
C57
4030009500 S.CER C1608 CH 1H 0R5B-T
T
51.4/25.5
C61
4030006860 S.CER C1608 JB 1H 102K-T
T
51.7/18.4
C62
4030006980 S.CER C1608 CH 1H 070D-T
T
46.8/21.4
C63
4030006860 S.CER C1608 JB 1H 102K-T
T
43.3/17.1
C64
4030011600 S.CER C1608 JB 1E 104K-T
T
43.3/19.7
C65
4030007040 S.CER C1608 CH 1H 180J-T
T
50.4/17.1
C71
4030009520 S.CER C1608 CH 1H 020B-T
T
42.9/21
C72
4030006860 S.CER C1608 JB 1H 102K-T
T
40.5/16.8
C73
4030007020 S.CER C1608 CH 1H 120J-T
T
36.5/19.7
C74
4030007100 S.CER C1608 CH 1H 560J-T
T
37.6/23.3
C75
4030007100 S.CER C1608 CH 1H 560J-T
T
35.8/23.2
C81
4030007020 S.CER C1608 CH 1H 120J-T
B
45/27.7
C82
4030007020 S.CER C1608 CH 1H 120J-T
B
46.5/18.9
C83
4030007090 S.CER C1608 CH 1H 470J-T
B
42.6/21.7
C91
4030007000 S.CER C1608 CH 1H 090D-T
B
52.9/16.3
C92
4030006860 S.CER C1608 JB 1H 102K-T
B
53.4/20
C96
4030006860 S.CER C1608 JB 1H 102K-T
B
51.1/34.9
C97
4030007090 S.CER C1608 CH 1H 470J-T
B
49.8/31.7
C98
4030006860 S.CER C1608 JB 1H 102K-T
B
48.5/31.7
C99
4030006860 S.CER C1608 JB 1H 102K-T
B
47.7/23.2
C103
4030007130 S.CER C1608 CH 1H 101J-T
B
53.4/34.1
C104
4030011600 S.CER C1608 JB 1E 104K-T
B
68.4/30.3
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
US=USA, US1=USA−1 S.=Surface mount
