6 - 3
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
IC1 1140005990 S.IC MB15A02PFV1-G-BND-ER B 34/35
IC141 1110002750 S.IC TA75S01F (TE85R) B 72.8/22.6
IC231 1110003200 S.IC TA31136FN (EL) B 17.6/11.3
IC251 1190000350 S.IC M62363FP-650C B 6.3/22.6
IC261 1110003800 S.IC NJM2904V-TE1 T 18.4/27.1
IC281 1130007300 S.IC TC4W66FU (TE12L) T 16.2/19.7
IC282 1130006220 S.IC TC4W53FU (TE12L) T 25.2/21.3
IC311 1120002830 S.IC NJM2125F-TE1 B 24.6/20.2
IC331 1190001860 S.IC EW-460-FT B 50.7/39.9
IC341 1130007570 S.IC BU4094BCFV-E2 B 15.8/22.1
IC381 1110004990 S.IC FX214LG/TR [US1] only B 18.3/34.6
IC382 1110003800 S.IC NJM2904V-TE1 B 7.7/35.2
IC383 1130007990 S.IC TC3W03FU (TE12L) T 17.1/35.9
Q1 1560000840
S.FET 2SK1829 (TE85R) T 29.6/35.5
Q2 1530002600 S.TR 2SC4215-O (TE85R) T 38.1/39.3
Q3 1560000540 S.FET 2SK880-Y (TE85R) T 29.2/31.7
Q41 1530002920 S.TR 2SC4226-T1 R25 T 49.2/32.5
Q47 1590001190 S.TR XP6501-(TX) .AB T 45.8/37.8
Q51 1530002920 S.TR 2SC4226-T1 R25 T 49.1/26.6
Q61 1530002380 S.TR 2SC4215-Y (TE85R) T 50.3/22.3
Q62 1530002380 S.TR 2SC4215-Y (TE85R) T 47.5/17.3
Q71 1530002380 S.TR 2SC4215-Y (TE85R) T 36.2/17.5
Q81 1590001400 S.TR XP1214 (TX) B 43.5/24.3
Q82 1590000430 S.TR DTC144EUA T106 B 40.4/22.6
Q91 1530003420 S.TR 2SC5110-O (TE85R) B 49.2/26.7
Q101 1560001240 S.FET RD01MUS1] T 60.2/28
Q111 1560001230 S.FET RD07MVS1 T 59.8/21.9
Q141 1590000720 S.TR DTA144EUA T106 B 72.6/19
Q165 1580000750 S.FET 3SK294 (TE85L) T 50.1/5.9
Q171 1560000840 S.FET 2SK1829 (TE85R) T 50.7/13.5
Q191 1580000760 S.FET 3SK299-T1 U73 T 35.9/4.5
Q211 1530002600 S.TR 2SC4215-O (TE85R) B 20.4/4.2
Q221 1530002690 S.TR 2SC4116-GR (TE85R) B 34.4/21.7
Q231 1590000720 S.TR DTA144EUA T106 B 10.9/16.7
Q232 1530003310 S.TR 2SC5107-O (TE85R) B 18.1/15.8
Q291 1590001650 S.TR XP4601 (TX) T 29.5/23.7
Q321 1510000670 S.TR 2SA1588-GR (TE85R) T 49.7/36.5
Q322 1510000670 S.TR 2SA1588-GR (TE85R) T 54.1/39.4
Q323 1510000670 S.TR 2SA1588-GR (TE85R) T 58/38.1
Q381 1590000430 S.TR DTC144EUA T106 T 25.1/34.8
D1 1790001250
S.DIO MA2S111-(TX) B 34.2/31.5
D2 1750000830 S.VCP HVC362TRF T 32.6/37.5
D3 1790001250 S.DIO MA2S111-(TX) T 35.8/40.9
D31 1750000710 S.VCP HVC350BTRF T 39.9/32.7
D32 1750000710 S.VCP HVC350BTRF T 40/30.7
D33 1750000710 S.VCP HVC350BTRF T 37.9/33.4
D34 1750000710 S.VCP HVC350BTRF T 40/29.4
D35 1750000710 S.VCP HVC350BTRF T 39.1/27.4
D36 1750000710 S.VCP HVC350BTRF T 40.5/27.4
D37 1750000710 S.VCP HVC350BTRF T 39.8/25.4
D38 1750000710 S.VCP HVC350BTRF T 39.8/24.1
D39 1720000400 S.VCP 1SV245 (TPH3) B 40.1/18.6
D91 1790000620 S.DIO MA77 (TX) B 50.3/16.1
D92 1790000620 S.DIO MA77 (TX) B 52/12.6
D121 1790001670 S.DIO RB706F-40T106 B 67.1/15.5
D131 1750000580 S.DIO 1SV307 (TPH3) T 63.8/5.6
D132 1790001210 S.DIO 1SS375-TL B 68.7/3.9
D141 1790001240 S.DIO MA2S728-(TX) B 69.3/14.2
D151 1750000580 S.DIO 1SV307 (TPH3) T 63.9/2.8
D152 1790000620 S.DIO MA77 (TX) T 57.8/2.8
D153 1750000580 S.DIO 1SV307 (TPH3) B 62.9/8.8
D154 1720000780 S.VCP HVU350B TRF B 61.6/4.1
D155 1720000780 S.VCP HVU350B TRF B 54.6/6.3
D171 1790001250 S.DIO MA2S111-(TX) T 54.5/7.9
D181 1720000780 S.VCP HVU350B TRF T 44.2/6.8
D182 1720000780 S.VCP HVU350B TRF T 40.7/6.1
D231 1750000520 S.DIO DAN222TL B 4.6/9.1
D232 1750000520 S.DIO DAN222TL B 8.1/10.9
FI211
2030000210 S.MLH FL-353 (31.05 MHz) B 29.8/6.9
FI231 2020001270 CER CFWLB450KE2A-B0
FI232 2020001410 CER CFWLB450KGFA-B0
X1
6050011070 S.XTL CR-664A (15.300 MHz) B 34/40
X231 6070000190 S.DCR CDBCB450KCAY24-R0 T 21.1/5.6
X381 6050011560 S.XTL CR-746 (4.000 MHz) [US1] only T 19.4/40.3
L31 6200005540
S.COL ELJNC R47K-F B 42.2/31.6
L32 6200009460 S.COL 0.25-1.9-7TL 67N T 37.1/31.2
L33 6200005540 S.COL ELJNC R47K-F B 42.4/28
L34 6200008390 S.COL 0.25-1.9-9TL T 37/26.5
L35 6200008380 S.COL 0.28-1.0-11TR 42N B 38/28.9
L41 6200008190 S.COL 0.25-1.9-8TL 80N T 42.7/29.5
L47 6200002610 S.COL NL 252018T-R47J B 49.1/36
[MAIN UNIT] [MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
L51 6200008390 S.COL 0.25-1.9-9TL T 44.1/24.7
L61 6200006980 S.COL ELJRE R10G-F T 48.1/20.6
L62 6200006980 S.COL ELJRE R10G-F T 46.1/19.4
L71 6200006980 S.COL ELJRE R10G-F T 38.1/17.7
L72 6200005720 S.COL ELJRE 33NG-F T 36.5/21
L81 6200007170 S.COL MLF1608A 3R3K-T B 47/26.9
L82 6200007170 S.COL MLF1608A 3R3K-T B 47.2/20.9
L92 6200005710 S.COL ELJRE 27NG-F B 50.5/29
L102 6200007690 S.COL LQW2BHN18NJ01L T 67.2/27.8
L112 6200008260 S.COL 0.30-1.7-8TL 60N T 65.7/21.1
L121 6200008510 S.COL 0.30-0.9-4TR 10.5N T 55.9/18.1
L122 6200008230 S.COL 0.30-1.3-5TL 22N T 56.9/12.7
L123 6200008280 S.COL 0.30-1.7-7TL 50N T 57.7/8
L124 6200003090 S.COL NL 322522T-2R7J-3 T 62.6/11
L131 6200009800 S.COL 0.26-1.1-7TR 30N T 66.9/9.7
L132 6200008580 S.COL 0.30-1.4-6TL 32N T 67.6/14.3
L151 6200008280 S.COL 0.30-1.7-7TL 50N T 67.2/3.6
L152 6200008280 S.COL 0.30-1.7-7TL 50N T 60.2/3
L153 6200003960 S.COL MLF1608A 1R0K-T B 62.8/11.2
L154 6200007750 S.COL LQW2BHN56NJ01L B 58.4/3.4
L155 6200007750 S.COL LQW2BHN56NJ01L B 52.2/4.1
L156 6200002150 S.COL ELJNC 56NK-F T 54.9/5.4
L165 6200003960 S.COL MLF1608A 1R0K-T T 46.5/11.5
L166 6200007750 S.COL LQW2BHN56NJ01L T 47.8/9
L181 6200007750 S.COL LQW2BHN56NJ01L T 41.4/3.4
L191 6200005540 S.COL ELJNC R47K-F T 34.7/8.5
L203 6200009180 S.COL ELJRE R10J-F3 B 41.2/4.5
L221 6200001980 S.COL NL 252018T-1R0J B 31.5/20
L222 6200001980 S.COL NL 252018T-1R0J B 26.1/14.9
R1 7030003700
S.RES ERJ3GEYJ 154 V (150 k Ω) B 28.4/28.8
R2 7030003240 S.RES ERJ3GEYJ 220 V (22 Ω) B 31.5/30.4
R3 7410000950 S.ARY EXB-V8V 102JV B 28.6/33.3
R4 7510001660 S.TMR NTCG16 4LH 473KT B 29.9/39.3
R5 7030003940 S.RES ERJ3GEYF 104 V (100 k Ω) B 29.9/42
R6 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 29.9/37.6
R7 7030003610 S.RES ERJ3GEYJ 273 V (27 k Ω) T 33.1/35.4
R8 7030003690 S.RES ERJ3GEYJ 124 V (120 k Ω) T 31.8/35.4
R9 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 29.3/40.9
R10 7030003760 S.RES ERJ3GEYJ 474 V (470 k Ω) T 29.6/33.6
R11 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) T 30.1/38.9
R12 7030003280 S.RES ERJ3GEYJ 470 V (47 Ω) T 40.3/39.2
R13 7030003670 S.RES ERJ3GEYJ 823 V (82 k Ω) T 38/41.3
R14 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) T 34.4/40.9
R15 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k Ω) T 39.7/37.3
R16 7030003290 S.RES ERJ3GEYJ 560 V (56 Ω) B 35.8/28.9
R17 7030003320 S.RES ERJ3GEYJ 101 V (100 Ω) B 39.2/34.6
R18 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) B 43.5/34.5
R19 7030003400 S.RES ERJ3GEYJ 471 V (470 Ω) B 44.9/34.5
R20 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) T 31.8/29.7
R21 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) T 31.3/31.7
R22 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k Ω) T 2.7/30.4
R31 7030003200 S.RES ERJ3GEYJ 100 V (10 Ω) B 44.6/31.8
R32 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) T 42.9/32.7
R33 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) T 36.9/29
R34 7030003200 S.RES ERJ3GEYJ 100 V (10 Ω) B 46/31.9
R35 7030003710 S.RES ERJ3GEYJ 184 V (180 k Ω) B 37.4/20.1
R36 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 37.7/17.5
R37 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 37.4/18.8
R38 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) B 36.3/14.7
R39 7030003680 S.RES ERJ3GEYJ 104 V (100 k Ω) B 40.4/16.2
R41 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k Ω) T 47.3/32.7
R42 7030006571 S.RES ERA3YED 392V T 45.4/33.2
R43 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7 Ω) T 48.2/29.6
R47 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k Ω) T 45.8/35.9
R51 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k Ω) T 46.3/28
R52 7030005331 S.RES ERA3YED 562V T 46/29.3
R53 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7 Ω) T 46.6/26.7
R61 7030003320 S.RES ERJ3GEYJ 101 V (100 Ω) T 49.7/19.1
R62 7030003660 S.RES ERJ3GEYJ 683 V (68 k Ω) T 52.2/22
R63 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7 Ω) T 45.5/21.4
R64 7030003640 S.RES ERJ3GEYJ 473 V (47 k Ω) T 45.3/17.4
R65 7030003320 S.RES ERJ3GEYJ 101 V (100 Ω) T 43.3/18.4
R71 7030003660 S.RES ERJ3GEYJ 683 V (68 k Ω) T 40.5/19.8
R72 7030003360 S.RES ERJ3GEYJ 221 V (220 Ω) T 40.5/18.1
R81 7030003380 S.RES ERJ3GEYJ 331 V (330 Ω) B 45.7/25.7
R82 7030003390 S.RES ERJ3GEYJ 391 V (390 Ω) B 45.2/21.9
R83 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 38.2/22.1
R91 7030003440 S.RES ERJ3GEYJ 102 V (1 k Ω) B 52.9/15
R92 7030003320 S.RES ERJ3GEYJ 101 V (100 Ω) B 50.1/22.1
R93 7030003560 S.RES ERJ3GEYJ 103 V (10 k Ω) B 50.1/19.3
R94 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k Ω) B 53.4/22.9
R95 7030003400 S.RES ERJ3GEYJ 471 V (470 Ω) B 52.5/27
R96 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k Ω) B 51.9/29.3
R97 7030003200 S.RES ERJ3GEYJ 100 V (10 Ω) B 51.1/32.1
R98 7030003320 S.RES ERJ3GEYJ 101 V (100 Ω) B 47.7/24.5
R101 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k Ω) B 67.3/31.6
R102 7030003620 S.RES ERJ3GEYJ 333 V (33 k Ω) B 66.9/27.7
R103 7030003300 S.RES ERJ3GEYJ 680 V (68 Ω) T 65.5/31.7
R111 7030003200 S.RES ERJ3GEYJ 100 V (10 Ω) T 65.5/24.7
US=USA, US1=USA−1 S.=Surface mount
