5 - 1
5-1 PREPARATION
When adjusting IC-M88, optional OPC-966 CLONING CABLE , optional RS-232C CABLE and optional CS-M88 adj ADJUSTMENT
SOFTWARE are required.
EQUIPMENT
DC power supply
RF power meter
(terminated type)
Frequency counter
Digital multimeter
GRADE AND RANGE
Output voltage : 7.2 V DC
Current capacity : 3 A or more
Measuring range : 0.1–10 W
Frequency range : 100–300 MHz
Impedance : 50
Ω
SWR : Less than 1.2 : 1
Frequency range : 0.1–300 MHz
Frequency accuracy : ±1 ppm or better
Sensitivity
: 100 mV or better
Input impedance : 10 M
Ω
/DC or better
EQUIPMENT
FM deviation meter
Audio generator
Standard signal
generator (SSG)
Attenuator
GRADE AND RANGE
Frequency range : 30–300 MHz
Measuring range : 0 to ±10 kHz
Frequency range : 300–3000 Hz
Measuring range : 1–500 mV
Frequency range : 100–300 MHz
Output level : 0.1 µV–32 mV
(–127 to –17 dBm)
Power attenuation : 40 dB or more
Capacity
: 10 W or more
SECTION 5 ADJUSTMENT PROCEDURES
SYSTEM REQUIREMENTS
• Microsoft ® Windows ® 95/98/ME
ADJUSTMENT SOFTWARE INSTALLATION
1. Boot up Windows ® .
- Quit all applications when Windows ® is running.
2. Insert the cloning software CD-ROM into the appropriate
CD-ROM drive.
3. Select ‘Run’ from the [Start] menu.
4. Type the setup program name using the full path name,
then push the [Enter] key. (For example; D:\ setup)
5. Follow the prompts.
6. Program group ‘CS-M88 ADJ’ appears in the ‘Programs’
folder of the [Start] menu.
STARTING SOFTWARE ADJUSTMENT
1. Connect IC-M88 and PC with the optional OPC-966 and
the RS-232C cable.
2. Boot up Windows ® , and turn the transceiver power ON.
3. Click the program group ‘CS-M88 ADJ’ in the ‘Programs’
folder of the [Start] menu, then CS-M88 ADJ’s window is
appeared.
4. Click ‘Connect’ on the CS-M88 ADJ’s window, then
appears IC-M88’s up-to-date condition.
5. Set or modify adjustment data as desired.
Microsoft and Windows are registered trademarks of
Microsoft Corporation in the U.S.A. and other countries.
Screen shots produced with permission from Microsoft
Corporation. All other products or brands are registered
trademarks or trademarks of their respective holders.
