PARTS LIST
KEY NO. DESCRIPTION Q’ty
1
Left Upright Beam 1
2 Right Upright Beam 1
3 Cross Brace 1
4 Main Seat Support 1
5 Leg Developer Holder 1
6 Seat Bracket 2
7 Crutch 2
8 Backrest Adjustment Bar 1
9 Left Butterfly 1
10 Right Butterfly 1
11 Leg Developer 1
12 Arm Curl Stand 1
13 Backrest Support 2
14 Foam Tube 2
15 Butterfly Handle 2
16 Backrest Board 1
17 Seat 1
18
Arm Curl Pad 1
19 4 3/8” x 1 ¾” Bracket 1
20 4 ¾” x 2 ¾” Bracket 2
21
∅
1 ¼” Rubber Bumper 1
22 Ø 2 ¾” Foam Roll 2
23 Ø 4” Foam Roll 4
24 Spring Clip 3
25 2 ¾” x 2” End Cap 4
26 M18 Lock Knob 3
27 M12 Lock Knob 2
28
∅
5/8” Bushing 4
29 Upright Beam Sleeve 2
30 Inner Cap 2
31
∅
1 ½” x 2” Rubber Bumper 2
32 1” Square End Cap 2
33 2” Sleeve 1
34 1 ½” Square End Cap 4
35 1 ¾” Square End Cap 2
36
∅
1” Cone-shaped End Cap 7
37
∅
1” End Cap 6
38
∅
5/8” Washer 10
39
∅
¾” Washer 14
40
∅
1” Washer 2
41 M12 Regular Nut 2
42 M10 x 2 ½” Carriage Bolt 4
43 M10 x 2 ¾” Carriage Bolt 4
44 M12 x 7 ¼” Hex Bolt 1
45 M12 x 5 ½” Hex Bolt 2
46 M10 x 2 ½” Allen Bolt 2
47 M10 x 5/8” Allen Bolt 2
48 M8 x 5/8” Allen Bolt 2
49 M8 x 1 5/8” Allen Bolt 8
50 M10 Aircraft Nut 10
51 M12 Aircraft Nut 1
52 ST2 Philips Screw 4
53 Bushing 2
54 Axle 1
