PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1
Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Front Post 1
5 Handle 1
6 Computer 1
7 Seat Post 1
8 Seat 1
9 Left Pedal 1
10 Right Pedal 1
11 Lock Knob 1
12 Ø 5/8” Washer 7
13 Ø 3/8” Lock Washer 3
14 M8 Aircraft Nut 4
15 M8 x 2 ½” Carriage Bolt 2
16 Ø 7/8“ Curved Washer 6
17 M8 Acorn Nut 2
18 M8 x 5/8“ Allen Bolt 8
19 Ø 1” Flat Washer 2
20 Upper Tension Cable 1
21 Middle Computer Wire 1
22 Lower Computer Wire 1
23 Lower Tension Cable 1
24 Front Stabilizer End Cap 2
25 Crank 1
26 M8 x 1 1/8” Screw 2
27 Rear Stabilizer End Cap 2
28 Upper Computer Wire 1
12
