Intel G41 EXPRESS CHIPSET PMG41-D2 User Manual
Page 12
10
(9) Serial-ATA Port connector:
SATA1 / SATA2 / SATA3/ SATA4
• These connectors support the provided Serial ATA and Serial ATA2 IDE hard disk cable
to connecting the motherboard and serial ATA hard disk.
(10)
Serial COM Port: COM1
COM1 is the 9-pin connector. The On-board serial port can be disabled through BIOS
SETUP.
(11) VGA Connector (15-pin D-Sub) Connector: VGA
VGA is the 15-pin D-Subminiature female connector for display monitor.
Primary IDE Connector
Pin 1
IDE1
IDE1
Serial-ATA1 & 2 Compatible Connectors
SATA2
SATA1
SATA4
SATA3
