FS-979 User’s Manual Introduction
Product Specification
9
Ethernet Interface
Chipset Intel® PRO/100 LAN interface with 82562EZ PHY
Or Marvell® Gigabit LAN interface with E8053 PCIE controller
82562EZ
10Base-T / 100Base-TX
auto-switching Fast Ethernet
Full duplex, IEEE802.3U compliant
Type
E8053
10Base-T / 100Base-TX/1000Base-T
auto-switching Gigabit Ethernet
Full duplex, IEEE802.3U compliant
Connector
External RJ45 connectors with LED on rear I/O panel
Solid State Disk Interface
Flash Type
Compact Flash Type-I/II for Compact Flash Card or Micro Drive
Capacity
Up to 1GB flash memory
ISA Interface
ISA Bridge
Winbond W83628F & W83629D
Function
I/O & IRQ supported only, no support DMA & bus mastering
Audio Interface
Chipset Intel® ICH6R with Realtek® ALC201A AC97 3D audio codec
Interface
2 channel 3D audio with Line-in, Line-out and MIC-in
Connector
Internal header for Line-out, Line-in and MIC-in
Internal CD audio connector
Power and Environment
Power
Requirement
Standard AT 4-pin power supply
Additional +12V 4-pin power connector
3-pin ATX function connector
Dimension
338 (L) x 122 (H) mm
Temperature
Operating within 0 ~ 60
o
C (32 ~ 140
o
F)
Storage within -20 ~ 85
o
C (-4 ~ 185
o
F)
Ordering Code
FS-979VDL
Full-size Intel® Pentium 4 PICMG single board computer with
LGA775, DDR2, AC97 Audio, CF, USB2.0, DVI, 10/100Mbps LAN
FS-979VDG3
Same with above but with 3 x Gigabit LAN
The specifications may be different as the actual board.
For further product information please visit the we
