Impex TC 3000 User Manual
Power station, Tc 3000, Model tc 3000
Table of contents
Document Outline
- BEFORE YOU BEGIN...................................................................................... 1
- IMPORTANT SAFETY NOTICES..................................................................... 2
- HARDWARE IDENTIFIER.....…....................................................................... 3
- ASSEMBLY INSTRUCTIONS........................................................................... 4
- EXPLODED DIAGRAM……………………………………………………………… 8
- PARTS LIST...................................................................................................... 9
- WARRANTY.................................................................................................…. 10
- ORDERING PARTS.......................................................................................… 10
- ASSEMBLY INSTRUCTION
- A.) Attach Left Support Frame (#6) onto the Rear Stabilizer (#2). Secure it with a M10 x 2 ½” Allen Bolt (#30) and ( ¾” Washer (#35) from the bottom up. Repeat the same step to install the Right Support Frame (#7) to the Rear Stabilizer.
- STEP 3 (See Diagram 3)
- A.) Attach the Left Dip Support (#8) and Right Dip Support (#9) to the Upper Vertical Frame (#5). Secure them with two M10 x 3 ¾” Carriage Bolts (#27), ( ¾” Washers (#35), and M10 Aircraft Nuts (#36).
- B.) Attach two Arm Pads (#15) to Left and Right Dip Supports. Secure each Pad with two M8 x 2 ¼” Allen Bolts (#33) and ( 5/8” Washers (#34).
- C.) Insert two Vertical Handles (#11) into the holes on the Dip Supports. Secure them with one M10 x 5/8” Allen Bolt (#31) and ( ¾” Washer (#35) underneath each handle. Slide two ( 1” Grips (#18) onto the Handles.
- E.) Slide two Sleeves (#21) onto the Handles on the Dip Supports. Then slide two ( 1 3/8” Grips (#17) onto the handles.
- STEP 4 (See Diagram 4)
- A.) Attach Backrest Pad (#16) to the Upper Vertical Frame (#5). Secure it with two M8 x 2 ¾” Allen
- Bolts (#32) and ( 5/8” Washers (#34).
- B.) Insert the Chin-up Bar (#10) into the top opening on the Upper Vertical Frame (#5). Secure it with one M10 x 3 ¼” Allen Bolt (#29), two ( ¾” Washers (#35), and one M10 Aircraft Nut (#36).
- C.) Slide two Chin-up Handle Grips (#20) onto both ends of the Bar (#10).
- E.) Insert the 2 ½” End Cap (#37) to the opening on the Chin-up Bar (#10).
- Parts list
- KEY NO. DESCRIPTION Q’ty
