35
6
SPEAKER-MICROPHONE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
■ Attachment
Attach the connector of the speaker-microphone into the [SP MIC]
jack on the transceiver and tighten the screw.
IMPORTANT: KEEP the [SP MIC] jack cover attached to the
transceiver when the speaker-microphone is not in use. (p. 3)
Water will not get into the transceiver even if the cover is not at-
tached, however, the terminals (pins) will become rusty, or the
transceiver will function abnormally if the connector becomes
wet.
CAUTION: Attach the [SP
MIC] jack snugly, but do
not overtighten.
A loose connection will al-
low water intrusion into
the jack; an overtightened
jack will damage the con-
nector pins in the trans-
ceiver.
