Back Cane and Attaching Hardware
NOTE: Chairs manufactured with a seat width, seat depth or back height of 20" and greater including all
heavy duty packages will be equipped with a spreader bar standard.
#1 Back Cane Assemblies
Back
Height
Back Cane-
No Push Handle
10 Deg. Bend
Back Cane-
Push Handle
Straight
Back Cane-
Push Handle
10 Deg. Bend
1049955 1045253 1045241 12"
1049956 1045254 1045242 13"
1049957 1045255 1045243 14"
1049958 1045256 1045244 15"
1045575 1048558 1048992 16"
1045576 1048559 1048993 17"
1045577 1048560 1048994 18"
1045578 1048561 1048995 19"
1045579 1048562 1048996 20"
1052227-NLA N/A N/A 21"
1052230 N/A N/A 22"
1054521 N/A N/A 23"
1054524 N/A N/A 24"
NOTE: Back Cane Assemblies include Foam Grips and Plug Buttons where shown
