Invacare Arrow - Manual (Page 149)

2-Pole Motor and Gearboxes
Before 7/1/98 1st Generation
Before 9/1/96 Storm RX
Item
Number
Description
Storm RX
Right
Storm RX
Left
1041510-NLA 1041509-NLA
Motor/
Gearbox
1
1050165-NLA 1050164-NLA Gear Box 2
1050163-NLA 1050162-NLA
Motor
Assembly
3
1050163E-NLA 1050162E-NLA
WARR RPLMT - Motor
Asbly
3
1050303 1050303 Brake
Repair Kit
4
See Note(s) A See Note(s) A
1044047-NLA 1044047-NLA
Brake Cover
4 Hole
Before 8/1/95
5
See Note(s) A See Note(s) A
1050304-NLA 1050304-NLA
Brake Cover
3 Hole
After 7/31/95
5
See Note(s) A See Note(s) A
1050305 1050305
Screw
(4-40 x 1/4")
6
1044044 1044044 Brushes w/Caps
(S) (Pair)
7
See Note(s) B See Note(s) B
1064336 1064336 Brushes w/Caps
(HD) (Pair)
7
See Note(s) B See Note(s) B
5165204-NLA 5165204-NLA NLA - Coupling w/ Cup (1"
Diameter)
8.
See Note(s) C See Note(s) C
50000X007 50000X007 Coupling w/ Cup (1-5/16"
Diameter)
8
See Note(s) D See Note(s) D
50000X341-NLA 50000X341-NLA Spacer 9
1043594 1043594
Screw
(1/4-20 x 1-1/8")
10
10502X001 10502X001 Lockwasher 11
A - Replacing brakes for chairs made before 8/1/95 require a 3-hole brake cover to replace the existing 4-hole cover. This change
may have already been done. Verify with the Customer which brake cover is present.
B - Motors with date code 1996 on the motor label (19 being the week of the year) will use (HD) Brushes. Motors with date code of
1996 or before use (S) Brushes.
C - Coupling with Cup for chairs manufactured before 11/12/01 - Use part # 50000X007 as a direct replacement part.
D - After 11/11/01 Coupling with Cup was resized from approximately 1" to 1-5/16" diameter and can be used as a direct
replacement for part number 5165204 NOTE:
