Invacare Arrow - Manual (Page 122)

Footrest and Legrest Accessories (continued)
AT5043 and AT5543 Heel Loops and Hardware
Footplate Type Part Number Consists of:
(2) Heel Loops
(4) Screw, Phillips Pan Head
(1/4-20 x 2-1/2")
(4) Spacer
(4) Locknut (1/4-20)
1160723
Kit, Heel Loop w/ Hardware,
Adjustable Angle Footplate (Pair)
AT5043 Flip-Up and AT5543
Adjustable Angle
(2) Heel Loops w/ Ankle Straps
(4) Screw, Phillips Pan Head
(1/4-20 x 2-1/2")
(4) Spacer
(4) Locknut (1/4-20)
1160724
Kit, Heel Loop w/ Ankle Strap and
Hardware, Adjustable Angle
Footplate (Pair)
AT5043 Flip-Up and AT5543
Adjustable Angle
(2) Screw, Phillips Pan Head
(1/4-20 x 2-1/4")
(2) Spacer
(1/4 x 11/32 x 1-3/4")
(2) Hex Nut w/ Nylon Cap (1/4-20)
(2) Flat Washer
(1/4 x 5/8 x 1/16")
1035931
Kit, Heel Loop Attaching Hardware
Attaching Hardware Only
Toe Loops and Attaching Hardware
1345 Toe Loops
Toe Loop
Single #
Toe Loop
Pair #
1037087 04572X025
Package Consists of: Part Number
(4) Screw Phillips Pan Head
(10-32 x 7/8")
(4) Washer
(1/4 x 3/4 x 3/32")
(4) Locknut (10-32)
1037089
Hardware, Toe Loop (Pair)
Hardware For:
1651, 1450, 1350
Footplates
121
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 94-113
