Width
16-17" Deep
Adjustable
18-19" Deep
Adjustable
20-21" Deep
Fixed
22" Deep
Fixed
1051935 1051924 1051913 1051902 14" W
1051936 1051925 1051914 1051903 15" W
1051937 1051926 1051915 1051904 16" W
1051938 1051927 1051916 1051905 17" W
1051939 1051928 1051917 1051906 18" W
1051940 1051929 1051918 1051907 19" W
1051941 1051930 1051919 1051908 20" W
1051942 1051931 1051920 1051909 21" W
1051943 1051932 1051921 1051910 22" W
1051944 1051933 1051922 1051911
23" W
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1051945 1051934 1051923 1051912
24" W
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
A - 23" Wide and over only available on heavy duty chairs. Heavy duty option is not available on STORM RX. NOTE:
Recliner Seat Frame Before 4/15/97
(17-1/2" S-T-F Standard LOW) or
(19" S-T-F Heavy Duty MEDIUM)
36
