BIOS Setup - 37 -
English
Onboard LAN Boot ROM
This function decide whether to invoke the boot ROM of the onboard LAN chip.
Enabled Enable this function.
Disabled Disable this function. (Default value)
Onboard Serial Port 1
Auto BIOS will automatically setup the port 1 address.
3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8. (Default value)
2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8.
3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8.
Disabled Disable onboard Serial port 1.
Onboard Serial Port 2
Auto BIOS will automatically setup the port 1 address.
3F8/IRQ4 Enable onboard Serial port 2 and address is 3F8.
2F8/IRQ3 Enable onboard Serial port 2 and address is 2F8. (Default value)
3E8/IRQ4 Enable onboard Serial port 2 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 2 and address is 2E8.
Disabled Disable onboard Serial port 2.
UART Mode Select
This item allows you to determine which Infra Red(IR) function of Onboard I/O chip.
Normal Set onboard I/O chip UART to normal mode. (Default value)
IrDA Set onboard I/O chip UART to IrDA mode.
ASKIR Set onboard I/O chip UART to ASKIR mode.
UR2 Duplex Mode
This feature allows you to seclect IR mode.
This function will available when "UART Mode Select" doesn't set at Normal.
Half IR Function Duplex Half. (Default value)
Full IR Function Duplex Full.
TxD, RxD Polarity Active
This function will available when "UART Mode Select" doesn't set at Normal.
Hi, Hi Set TxD, RxD polarity active to Hi, Hi.
Hi, Lo Set TxD, RxD polarity active to Hi, Lo.
Lo, Hi Set TxD, RxD polarity active to Lo, Hi. (Default value)
Lo, Lo Set TxD, RxD polarity active to Lo, Lo.
Use IR Pins
This function will available when "UART Mode Select" doesn't set at Normal.
RxD2, TxD2 Set IR pins to use RxD2, TxD2.
IR-Rx2Tx2 Set IR pins to use IR-Rx2Tx2. (Default value)
Only for GA-8IPE1000-G.
Only for GA-8IPE1000-L.
