7 list of jumpers – Intel CV702A User Manual
Page 21
17
NOTE!
When you install DIMM module fully into the DIMM socket, the eject tab should be
locked into the DIMM module very firmly and fit into its indention on both sides.
WARNING!
2. Once you hear " Beep Beep Beep" sounds after turning on the power ,
please check if the DRAM is installed properly or not.
2-7 List of Jumpers
JB1: CMOS DATA SET
JCF1: CF card mast and slave select
JCF2: CF card Voltage select
