IBM EP-8KTA - Manual (Page 2)

EP-8KTA
Table of Contents
Section 1 Introduction
Components Checklist ........................................ 1-1
Overview
AMD Duron TM & Athlon TM Processors ............. 1-2
Accelerated Graphics Port .................................. 1-3
Hardware Monitoring .......................................... 1-3
EP-8KTA Form-Factor........................................ 1-4
I/O Shield Connector .......................................... 1-5
Power-On/Off (Remote) ..................................... 1-5
System Block Diagram........................................ 1-6
Section 2 Features
EP-8KTA Features ............................................... 2-1
Section 3 Installatio
n
EP-8KTA Detailed Layout .................................. 3-2
Easy Installation Procedure
CPU Insertion ...................................................... 3-3
Jumper Settings ................................................... 3-5
System Memory Configuration .......................... 3-7
Device Connectors .............................................. 3-9
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ............. 3-12
STR (Suspend To RAM) Function ....................... 3-13
Section 4 Award BIOS Setup
Main Menu ........................................................... 4-1
Standard CMOS Setup ......................................... 4-2
Advanced BIOS Features ..................................... 4-3
Advanced Chipset Features ................................. 4-8
Integrated Peripherals ......................................... 4-11
Power Management Setup ................................... 4-15
PNP/PCI Configuration ...................................... 4-18
PC Health Status .................................................. 4-20
Frequency/Voltage Control ................................. 4-21
