Appendix - 63 -
English
5.1 Channel Audio Setup
STEP 1 :
Connect the front speaker to "Front Speaker Out", the
surround speaker to "Surround speaker out", and the
center/subwoofer speaker to "Center/Subwoofer
Speaker Out".
STEP 2:
After installation of the audio driver, you find an
icon in the system area. Double click the icon to
select the function.
Surround speaker
out
Front Speaker Out
Center/Subwoofer
Speaker Out
STEP 3:
Click "C-Media 3D Audio Configuration" and then
select "Main Setting". The current audio mode is
display in "Audio System Status". "Smart Jack"
would auto-detect the speaker type you connect
and gives you the functions to manually modify
speaker the settings.
The function to
manually modify
speaker setting.
The function to
adjust speaker
volume.
