PARTS LIST
KEY NO. DESCRIPTION Q’ty
1
Left Upright Beam 1
2 Right Upright Beam 1
3 Cross Brace 1
4 Main Seat Support 1
5 Leg Developer Holder 1
6 Front Stabilizer 1
7 Crutch 2
8 Backrest Adjustment Bar 1
9 Left Butterfly 1
10 Right Butterfly 1
11 Leg Developer 1
12 Arm Curl Stand 1
13 Backrest Support 2
14 Foam Tube 3
15 Butterfly Handle 2
16 Backrest Board 1
17 Seat 1
18
Arm Curl Pad 1
19 4 3/8” x 1 ¾” Bracket 1
20 4 ¾” x 2 ¾” Bracket 2
21 Backrest Incline Support 1
22 Ø 2 ¾” Foam Roll 4
23 Ø 4” Foam Roll 4
24 Spring Clip 3
25 Ø 5/8” Washer 10
26
∅
¾” Washer 14
27 2 ¾” x 2” End Cap 4
28 1” Square End Cap 3
29 1 ½” Square End Cap 6
30 2” Square End Cap 2
31 Ø 1” Cone-shaped End Cap 3
32 Ø 1” End Cap 9
33 Foam Roll End Cap 4
34 Rubber Bumper 2
35 M12 Regular Nut 2
36 M10 x 2 3/8” Carriage Bolt 1
37 M10 x 2 ½” Carriage Bolt 4
38 M10 x 2 ¾” Carriage Bolt 4
39 M12 x 5 ½” Hex Bolt 2
40 M10 x 2 7/8” Allen Bolt 1
41 M10 x 5/8” Allen Bolt 3
42 M8 5/8” Allen Bolt 2
43 M8 x 1 5/8” Allen Bolt 8
44 Bushing 2
45 M12 Lock Knob 2
46 2” x 2” Sleeve 1
47 M10 Aircraft Nut 10
48 M18 Lock Knob 3
49 L-shaped Pin 1
50 Butterfly Bushing 4
51 Upright Beam Sleeve 2
52 Inner Cap 2
53 Philip Screw 4
