Installing DIMMs

To make sure you have the correct DIMM, place the DIMM on the illustration in Figure 16
showing the DDR2 DIMM. All the notches should match with the DDR2 DIMM.

OM16943

1 2 3 4 5 6

DDR

DDR2

7 8 9 10 11 12 13

Figure 16. Use DDR2 DIMMs
