Page 31
Installing and Replacing Desktop Board Components
31
Installing the Processor Fan Heat Sink
Desktop Board D955XCS has an integrated processor fan heat sink retention mechanism (RM).
For instructions on how to attach the processor fan heat sink to the integrated processor fan heat
sink RM, refer to the boxed processor manual or the Intel World Wide Web site at:
Connecting the Processor Fan Heat Sink Cable
Connect the processor fan heat sink cable to the 4-pin processor fan header (see Figure 12).
OM17781
I
J
Figure 12. Connecting the Processor Fan Heat Sink Cable to the Processor Fan Header
Removing the Processor
For instructions on how to remove the processor fan heat sink and processor, refer to the processor
installation manual or the Intel World Wide Web site at:
