47
IS-PD7BL portable DVD player
www.insignia-products.com
• If connected to a battery:
•
Make sure that the battery is secured in place on the back
of the DVD player.
• Make sure that the battery is fully charged.
• Make sure that the battery and AC adapter are both
plugged in. If so, disconnect the AC adapter.
Specifications
Laser Wavelength 650 nm
Video system NTSC
Frequency
response
20 Hz ~ 20 KHz ±1dB
Signal/noise ratio >95dB
Audio distortion +
noise
< -80 (1 KHz)
Channel separation > 85dB
Dynamic range > 85dB
Output
Audio out
(analog
audio) Output level: 2V ±10%
Load impedance: 10 K Ohms
Audio out
(digital
audio) Output level: 0.5Vp-p
Video out Output level: 1Vp-p ±20%
Load impedance: 75 Ohm,
imbalance, negative polarity
Power supply CD 9V 2A
Allowable motion
temperature
41 ~ 95°F (5 ~ 35°C)
Power consumption < 20W
Dimensions 8.82 Ч 6.65 Ч 1.24 inches (224 Ч
169 Ч 31.5 mm)
Weight About 1.76 lbs. (0.8 kg)
