Advanced setup
Making optional connections
C
ONNECT
TO
A
TV
THROUGH
THE
COMPOSITE
VIDEO
OUTPUT
•
Mini plug: Connect to the AV OUT jack of the DVD player.
•
Yellow plug: Connect to the VIDEO IN jack of the TV.
•
Red plug: Connect to the AUDIO IN R jack of the TV.
•
White plug: Connect to the AUDIO IN L jack of the TV.
AV O UT
C OAX IAL
AV IN
V O LUME
DC O UT 5V
DC IN 9V
TV
VIDEO IN
AUDIO IN R
AUDIO IN L
S-VIDEO IN
Composite video connections
AV O UT
C OAX IAL
AV IN
V O LUME
DC O UT 5V
DC IN 9V
TV
VIDEO IN
AUDIO IN R
AUDIO IN L
R-SPEAKER
L-SPEAKER
OPNCAL
LINE IN
SPEAKWRS
AMP
R
L
R
L
TV and amplifier connections
