Cable de alimentación: Conecte el reproductor de DVD (DC
OUT) (salida de CC) al sintonizador (DC IN) (entrada de CC).
•
Mini conector: Conecte al terminal AV IN (entrada de AV) en
el reproductor.
•
Conector amarillo: Conecte al terminal VIDEO OUT (salida
de video) del sintonizador.
•
Conector rojo: Conecte al terminal AUDIO IN R (entrada de
audio derecha) del sintonizador.
•
Conector blanco: Conecte al terminal AUDIO IN L (entrada
de audio izquierda) del sintonizador.
V HF /UHF
T V Tu n e r ( o p t i o n a l )
AV O UT
C OAX IAL
AV IN
V O LUME
DC O UT 5V
DC IN 9V
DC IN
R - AUDIO - L
VIDEO
D V D P l a y e r
