INSTALLATIONS
12 MB890 User’s Manual
Connectors on MB875
The connectors on MB875 allows you to connect external devices such
as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB875 and their respective
functions.
Connector Locations on MB875 .......................................................... 13
J1: VGA CRT Connector ..................................................................... 14
J2: COM2 Serial Port ........................................................................... 14
J4: USB Connector .............................................................................. 14
J5: SATA HDD Connector .................................................................. 15
J6: SATA HDD Connector .................................................................. 15
J7: COM3 Serial Port ........................................................................... 15
J8: COM4 Serial Port ........................................................................... 16
J9: Case Open Detect Header .............................................................. 16
J10: ATX Power Connector ................................................................. 16
J11: Keyboard / Mouse Connector ...................................................... 17
J12: Power On & Reset Headers .......................................................... 17
SW1: Digital I/O Input Pin Switch ...................................................... 17
LED1: Digital IO Output LED ............................................................ 17
LED2: HDD / Power LED ................................................................... 17
CN2, CN3, CN4, CN5: LAN Connectors ............................................ 17
CN6: USB Connector .......................................................................... 17
