SECTION 5—OPERATING INSTRUCTIONS

FIGURE 5.3 Humidifier Compartment

Power Switch

NOTE: For this procedure, refer to
FIGURE 5.4.

1. Press power switch to on

position. All the panel
lights and the audible
alarm will come on for
one second, indicating
that the unit is functioning
properly.

FIGURE 5.4 Power Switch

Humidifier

Bottle

Humidifier

Compartment

Humidifier

Bottle

Adapter

Humidifier

Bottle

DETAIL “A”

DETAIL “B”

Oxygen

Tubing

Oxygen Outlet

Connector

Humidifier

Bottle

Outlet

On/Off

(I/O)

Power
Switch
