Appendix
LitePro 760 User’s Guide 45
“Monitor” and “Computer” Connectors
The pin assignments are the same for the “Monitor” and “Computer”
connectors. The “Monitor” connector is a female video RGB, 15-pin
micro-D-style connector. The “Computer” connector is a male video
RGB, 15-pin micro-D-style connector. The table below lists the pin
assignments for both connectors.
Pin Signal Description
1 Red analog input
2 Green analog input with composite sync
3 Blue analog input
4 GND
5 GND
6 Red GND
7 Green GND
8 Blue GND
9 NC
10 Sync GND
11 GND
12 NC
13 Horizontal sync/composite sync input
14 Vertical sync input
15 NC
