PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Stabilizer
2
2 Rear Support 2
3 Upright Beam 2
4 Cross Brace 2
5 Guide Rod 2
6 Safety Stop 2
7 Safety Hook 2
8 Sliding Bar Catch 2
9 Weight Bar 1
10 Lifting Sleeve 1
11 Weight Storage Post 2
12 4 ¾” x 2” Bracket 6
13 6 ¼” x 2” Bracket 2
14
∅
¾” Washer 36
15 M10 x 5/8” Allen Bolt 2
16 M8 x ½” Allen Screw 7
17 M10 Aircraft Nut 28
18 M10 x 2 ¾” Carriage Bolt 20
19 M10 x 2 ½” Allen Bolt 2
20 M10 x 1 5/8” Allen Bolt 2
21
∅
2” End Cap 2
22
∅
1 ½” Spacer 12
23 1” x 2” End Cap 4
24 2” Stabilizer End Cap 8
25
∅
3” Rubber Spacer 2
26
∅
2 ½” x 1” Rubber Bumper 2
27 Long Olympic Sleeve 2
28 Shoulder Pad 1
29 Spring Clip 5
30 Main Seat Support 1
31 Seat Pad 1
32 Backrest Board 1
33 Backrest Support 2
34 Backrest Incline Support 1
35 Rear Stabilizer 1
36 Front Stabilizer 1
37 Foam Tube 3
38 Foam Roll 6
39 Leg Developer 1
40 Ø 2” End Cap 2
41 L-shaped Pin 1
42 Seat Incline Support 1
43 Foam Roll End Cap 6
44
∅
1” End Cap 3
45 ¾” x 1 5/8” End Cap 4
46 1 ½” Square End Cap 1
47 M10 x 7 ¼” Allen Bolt 2
48 M10 x 4 ¾” Allen Bolt 1
49
∅
½” Washer 8
50 M6 x 2 1/8” Hex Bolt 4
51 Leg Developer Bushing 2
52 M10 x 3 1/8” Allen Bolt 1
53 M6 x 5/8” Hex Bolt 4
54 2” Square End Cap 1
55 Olympic Sleeve 1
